22
Menu selection
Betriebsdaten (Operat-
ing data)
Associated datapoints can be changed (write) via the EIB
system.
Kessel (Boiler) Associated datapoints can be read (read) via the EIB sys-
tem.
Heizkreis A1/M1 (Heat-
ing circuit A1/M1)
Heizkreis M2 (Heating
circuit M2)
Heizkreis M3 (Heating
circuit M3)
Warmwasser (DHW)
Solar
Datapoints overview: The list can be
downloaded from www.viessmann.de/
vitogate-200-eib.
6. Datenpunkt
Menu for the selection of a datapoint to
be assigned to the corresponding com-
munication object.
Selection subject to the entries under
"Regelung", "Dienst" and "Gruppe".
Datapoints overview: The list can be
downloaded from www.viessmann.de/
vitogate-200-eib.
7. Zykluszeit
Menu for the selection of the transmis-
sion interval to be assigned to the corre-
sponding communication object.
Menu selection Explanation
5 s bis 120 min (5 s to
120 min)
The value of this datapoint is transmitted cyclically to the
EIB system in accordance with the selected interval.
nicht zyklisch senden
(do not transmit cycli-
cally)
The value of this datapoint is either never transmitted to
the EIB system or only in the case of a change.
Note
The shorter the cycle time, the higher the
BUS load.
Example:
Cycle time: 5 s
Assigned communication objects: 34 (32
datapoints + error bit + error byte)
Telegrams per min:
(60 s : 5 s) x 34 = 408
8. Max Abweichung gegenüber
zuletzt gesendeten Wert
Menu for the selection of the transmis-
sion interval subject to the setting of the
cycle time.
Commissioning
Parameters in ETS
(cont.)
