24
Menu selection Explanation
5 s bis 120 min (5 s to
120 min)
The fault message is transmitted cyclically to the EIB sys-
tem in accordance with the selected interval.
nicht zyklisch senden
(do not transmit cycli-
cally)
The fault message is either never transmitted to the EIB
system or only in the case of a change.
Note
The shorter the cycle time, the higher the
BUS load (for example, see page 22).
Max Abweichung (Max deviation)
Menu for the selection of the transmis-
sion interval subject to the setting of the
cycle time.
Menu selection Explanation
nie senden (Never
transmit)
The fault message is never transmitted to the EIB sys-
tem.
bei jeder Änderung sen-
den (transmit after every
change)
The fault message is transmitted to the EIB system follow-
ing every change from "0" to "1" or from "1" to "0" .
1: There is a fault
0: No fault
Error byte
Example with ETS3
Commissioning
Parameters in ETS
(cont.)
5592 880 GB
