Viessmann Vitomax HS M95 - Page 52

52
6
5
9 7
qP
8
Fig. 19
1 8
3
4
2
Ordering information
Enter the serial no. of the boiler, the type and amount required. Obtain commercially available parts from your
local trade supplier.
Order forms
Serial no.:
Vitomax HS, type M73 size
*12
1 2 3 4 5 6 7 8 9
Pos. Component Quan-
tity
Quan-
tity
Quan-
tity
Quan-
tity
Quan-
tity
Quan-
tity
Quan-
tity
Quan-
tity
Quan-
tity
1 Packing per boiler door
2 Packing per boiler door
3
*13
Insulation ring (optional)
4
*13
Burner connection packing
5
*13
Cleaning cover packing
6
*13
Rear boiler floor packing
7
*13
Packing per inspection port
8 Handhole gasket
100 x 150 mm
Manhole gasket
325 x 425 mm
*12
The last digit of the part number indicates the boiler size.
*13
A sufficient quantity of installation adhesive is provided.
Wearing parts
Wearing parts and gaskets
5837984
Components
