Softener Parts List
Key
No.
Part No. Description
1 7366130
P
ower Supply, 24V DC,
with Snap-in Plugs for Europe & UK
2 7250826 Power Cable
3 7388491 Repl. Electronic Controller (PWA)
4 7351876 Top Cover / Faceplate
5 7351884 Faceplate Decal / Keypad
6
7310113 Brine Valve Assembly, (Model VS 34)
7310163 Brine Valve Assembly, (Model VS 74)
7310202
Brine Valve Assembly,
(Models VS 87 & VS 124)
7
7269516
Float, Stem & Guide Assembly
(Model VS 34)
7293395
Float, Stem & Guide Assembly
(Model VS 74)
7327568
Float, Stem & Guide Assembly
(Models VS 87 & VS 124)
8 7337301 Salt Lid
9
0500283 Cover, Brinewell (Model VS 34)
7155115
Cover, Brinewell
(Models VS 74, VS 87 & VS 124)
10
7267043
Brinewell Assembly, including
salt level decal (Model VS 34)
7267027
Brinewell Assembly, including
salt level decal (Model VS 74)
7214375
Brinewell Assembly, including
salt level decal (Model VS 87)
7137824
Brinewell Assembly, including
salt level decal (Model VS 124)
– 7331672
Brinewell Mounting Hardware Kit,
Model VS 34
(includes Key Nos. 11-12)
– 7331698
Brinewell Mounting Hardware Kit,
Models VS 74, VS 87 & VS 124
(includes Key Nos. 11 & 12)
11
á
Nut (Model VS 34) or
Washer (other VS models)
¢ á
Spacer (Model VS 34 only)
12
á
Screw
Key
No.
Part No. Description
13
7268918 Repl. Brine Tank (Model VS 34)
7268934 Repl. Brine Tank (Model VS 74)
7337424 Repl. Brine Tank (Model VS 87)
7337408 Repl. Brine Tank (Model VS 124)
– 7331258
Overflow Hose Adaptor Kit
(includes Key Nos. 14-16)
14
á
Hose Clamp
15
á
Adaptor Elbow
16
á
Grommet
17
RMH001 Resin, per liter
30437 Resin, 25 liter bag
18 7105047 Repl. Bottom Distributor
19
7268950
Resin Tank, 22.9 cm dia. x 35.6 cm
(Model VS 34)
7264037
Resin Tank, 20.3 cm dia. x 63.5 cm
(Model VS 74)
7114787
Resin Tank, 20.3 cm dia. x 88.9 cm
(Model VS 87)
7113058
Resin Tank, 20.3 cm dia. x 101.6 cm
(Model VS 124)
– 7331177
Tank Neck Clamp Kit
(includes 2 ea. of Key Nos. 20 & 21)
20
á
Retainer Clip (2 req.)
21
á
Clamp Section (2 req.)
22 7265025 Screen (Model VS 34 only)
23
7088855 Top Distributor (Model VS 34)
7077870
Top Distributor
(Models VS 74, VS 87 & VS 124)
– 7112963
Distributor O-Ring Kit
(includes Key Nos. 24-26)
24
á
O-Ring, 69.9 x 76.2 mm
25
á
O-Ring, 20.6 x 27.0 mm
26
á
O-Ring, 73.0 x 82.6 mm
27 7225499 Locking Plate
28 7139999 Drain Hose, 6 meters
¢ Not illustrated
