1. Pull the dummy adaptor out down-
wards.
2. Route the cable to terminals X11
and X13 on the PCB.
Insert the strain relief.
3. Plug connectors X11 and X13 into
the PCB.
4. Connect the connector to the WiFi
module. Insert the WiFi module into
the control unit support from below.
5. Close the control unit enclosure in
reverse order – see page 7.
6. Start up the WiFi module – see
page 11.
Installing the WiFi module in the Vitopend
(cont.)
5838175
