Key Code (HEX)
1 01
2 02
3 03
4 04
5 05
6 06
7 07
8 08
9 09
0 0A
- 0B
RECALL (LAST) 0C
INFO (DISPLAY) 0D
0E
ASPECT (ZOOM, SIZE) 0F
VOLUME UP (+) 10
VOLUME DOWN (-) 11
MUTE 12
CHANNEL/PAGE UP (+)/
BRIGHTNESS+
13
CHANNEL/PAGE DOWN (-)/
BRIGHTNESS-
14
POWER 15
SOURCES (INPUTS) 16
17
18
SLEEP 19
MENU 1A
UP 1B
DOWN 1C
LEFT (-) 1D
RIGHT (+) 1E
OK (ENTER, SET) 1F
EXIT 20
21
22
23
24
25
26
27
28
29
2A
2B
RED ■ (F1) 2C
GREEN ■ (F2) 2D
YELLOW ■ (F3) 2E
BLUE ■ (F4) 2F
NOTE:
1. This IR-pass-through code is dierent from the
RCU key code.
2. Special control sequence for POWER key
under IR-pass through mode.
2-1. When Commercial Display is OFF
and receives the IR POWER code:
Commercial Display will turn itself on,
then forward the POWER code to the
host via RS232.
2-2. When Commercial Display is ON
and receives the IR POWER code:
Commercial Display will forward the
POWER code to the host via RS232,
then turn o itself.
2-3. When SET-POWER LOCK is enabled,
the Commercial Display will not respond
to POWER key pressing.
3. The VOLUME UP and VOLUME DOWN code
will repeatedly output when you press and hold
the keys.
