86
Tiling-Mode 8 s P 50 000: OFF
001: ON
(for video wall)
Tiling-Com-
pensation
8 s Q 51 000: OFF
001: ON
(for video wall)
Bezel width compensa-
tion
Tiling-H by V
Monitors
8 s R 52 01x~09x: H
0x1~0x9: V
(for video wall)
1. 2nd digital for H
monitors
2. 3rd digital for V moni-
tors
Tiling-Posi-
tion
8 s S 53 001~025 (for Video wall)
Copy the screen of
Position# to identified
display
Date: Year 8 s V 56 Y17~Y99 Last 2 digits
(20)17~(20)99
Date: Month 8 s V 56 M01~M12 2 digits
Date: Day 8 s V 56 D01~D31 2 digits
Time: Hour 8 s W 57 H00~H23 24-hr format. 2 digits.
Time: Min 8 s W 57 M00~M59 2 digits
Time: Sec 8 s W 57 S00~S59 2 digits
Note:
1. Tiling definition of H Monitors/ V Monitors/ and Position
2. Set Date example
Date: 2017-3/15
Send: 0x 38 30 31 73 56 59 31 37 0D (“Y17”)
Send: 0x 38 30 31 73 56 4D 30 33 0D (“M03”)
Send: 0x 38 30 31 73 56 44 31 35 0D (“D15”)
