ViewSonic P225f 11
Other Information
Preset Timing Modes
(Recommended Timing Mode for this monitor is:
pre-adjusted to VESA 1600 x 1200 @ 85 Hz.)
1
Macintosh models prior to G3 require a Macintosh adapter. To order a Macintosh adapter, contact
ViewSonic Customer Support. You will need to provide serial number of the product.
2
Warning: Do NOT set the graphics card in your computer to exceed these Maximum Refresh Rates;
doing so could result in permanent damage to the monitor.
Specifications
CRT Ty p e
Phosphor
Glass surface
22” (20.0” viewable diagonal area),
0.24 mm aperture grill pitch,
90
o
deflection
RGB, medium-short persistence
Anti-reflection, anti-static coating
Standard light transmission rate = 39.8%
Input Signal Video
Sync
RGB Analog (0.7 Vp-p, 75 Ohms)
f
H
: 30-127 kHz, f
v
: 50-180 Hz
HV Separate (TTL), Composite, Sync on Green
Compatibility PC
Macintosh
1
VGA up to 2048 x 1536
Power Macintosh (may require Macintosh adapter)
Timing Modes with
Maximum
Refresh
Rates
2
2048 x 1536 NI @ 79 Hz 1280 x 1024 NI @ 115 Hz
1920 x 1440 NI @ 84 Hz 1152 x 864 NI @ 135 Hz
1856 x 1392 NI @ 86 Hz 1024 x 768 NI @ 151 Hz
1792 x 1344 NI @ 89 Hz 800 x 600 NI @ 180 Hz
1600 x 1200 NI @ 99 Hz 640 x 480 NI @ 180 Hz
Power Voltage AC 100-240V (auto switch) 50/60 Hz
Display Area Default
Full scan
396 mm (H) x 297 mm (V) (Typical)
400 mm (H) x 300 mm (V) (Depends on signal timing)
Operating
Conditions
Temperature
Humidity
Altitude
32° F to 104° F(0° Cto+40° C)
5% to 95% (no condensation)
To 10,000 feet
Storage Conditions Temperature
Humidity
Altitude
-40° F to +140° F(-40° Cto+60° C)
5% to 95% (no condensation)
To 40,000 feet
Dimensions Physical
(monitor)
508 mm (W) x 502 mm (H) x 500 mm (D)
20.0” (W) x 19.8” (H) x 19.7” (D)
Weight Net 30.5 kg (67.1 lb.) (monitor only)
Regulations UL, DHHS, FCC-B, CE, CB, CSA, ISO 9241-3, ICES003, Nemko, Semko,
Demko, Fimko, NOM, IRAM, TUV/GS, VCCI, BSMI, PSB, C-Tick, TUV-Ergo,
MPR-II, S. Africa, PCBC, GOST, SASO, CCIB, CCEE, EMI-B, TCO’99
Power Saving
Modes
On
DPMS
TM
Standby
DPMS
TM
Suspend
DPMS
TM
Off
< 170W NORMAL (Green LED)
< 15W (Orange LED)
< 15W (Orange LED)
< 3W (Flashing Orange LED)
VGA 640 x 400 @ 70 Hz
VESA 800 x 600 @ 75 Hz
VESA 800 x 600 @ 85 Hz
VESA 1024 x 768 @ 75 Hz
VESA 1024 x 768 @ 85 Hz
VESA 1280 x 1024 @ 75 Hz
VESA 1280 x 1024 @ 85 Hz
VESA 1600 x 1200 @ 75 Hz
VESA 1600 x 1200 @ 85 Hz
VESA 1920 x 1440 @ 75 Hz
VESA (GTF) 2048 x 1536 @ 75 Hz
Macintosh 1152 x 870 @ 75 Hz
