ViewSonic Corporation’s QMS & EMS have been registered
to ISO 9001 & ISO 14001, respectively, by the British Standards Institution.
ViewSonic
®
• TCO ’99 and Energy certified
This monitor complies with the world’s
strictest standards of low radiation,
safety, ergonomics, recycling and power
management while saving
costs through automatic
power saving modes.
•
Fully supports the Microsoft
®
Windows
®
auto installation standard for easy, trouble-
free configuration and set-up.
• PC and Mac
®
compatible
• Three-year limited warranty
24/7 free technical and customer service.**
17" (16.0" VIEWABLE) PROFESSIONAL COLOR MONITOR WITH PERFECTFLAT
®
CRT Type 17" (16.0" diagonal viewable area) 90° deflection
0.25mm aperture grille pitch
Phosphor RGB B22 medium-short persistence
Glass Surface Tint (TM=41.5%), ARAG
®
screen treatment
INPUT SIGNAL
Video RGB analog (0.7Vp-p, 75 ohms)
Sync H/V separate (TTL), composite sync, sync-on-green
Frequency F
h
:30-97kHz, F
v
:50-180Hz
COMPATIBILITY
PC IBM
®
XT, AT, 386, 486, Pentium
®
, PS/2 and
compatibles (from VGA up to 1,600 x 1,200)
Mac
®
* Power Mac
™
,G3
Other Most workstations
CONNECTOR
Signal 15-pin mini D-sub (attached cable)
Power 3-pin plug (IEC320)
POWER
Voltage AC 90–260V, 50–60 (+/-2)Hz
Consumption 130W (max)
USER CONTROLS
Basic Power, 1, down, up, 2
OnView
®
Contrast, brightness, H/V-position, H/V-size, pincushion, trape-
zoid, pin-balance, parallelogram, rotation, degauss, purity, V
linearity center, V linearity symmetry, moiré reduction,
ViewMatch
®
color, H/V focus, H/V convergence,ViewMeter
®
,
H/V OSD position, language, zoom, hooking, data recall
VIDEO INPUT Bandwidth 200MHz (typ)
MISCONVERGENCE 0.25mm (max at center)
0.35mm (max at corner)
DISPLAY AREA
Factory Setting 300mm (H) x 225mm (V) (Dependent upon
Maximum Scan 325mm (H) x 243mm (V) signal timing used)
OPERATING
Temperature 32°F to 104°F (0°C to 40°C)
CONDITION Humidity 5% to 95% (no-condensation)
DIMENSIONS
Physical 417mm (W) x 430mm (H) x 450mm (D)
(16.4" x 16.8" x 17.7")
WEIGHT Net 20.0Kg (44.1 lbs.)
OTHER DDC1, DDC2B, GTF
REGULATIONS UL, CSA, FCC-B, DHHS, E
NERGY STAR
®
, TCO ’99, Energy 2000,
TUV/GS, CE, CB, MPR-II, BCIQ, VCCL, C-TICK, NEMKO,
DEMKO, SEMKO, FEMKO, PCT, SASO, PTB, NOM, ISO 9241-3,
S-MARK
POWER MANAGEMENT Meets VESA
®
DPMS, TCO ’99 and Energy standards
WARRANTY Three-year limited warranty on CRT, parts and labor.
48-hour Express Exchange
®
service option available.
*Adapter may be required. Analog adapter available from ViewSonic. **Excludes major U.S. holidays. Specifications subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for
complete details. Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2003 ViewSonic Corporation. All rights reserved. [10550-01B-03/03_0M] PF775-1
Professional Series
PF775 Monitor
ViewSonic Corporation • 381 Brea Canyon Road, Walnut, CA 91789
Phone (800) 888-8583 or (909) 444-8888 • In Canada (866) 262-1967 • Fax (909) 839-7922 • SalesInfo@ViewSonic.com • ViewSonic.com
