10ViewSonic PJ506D
1 SERIE
Cuando trabaje con el proyector a través de un ordenador, conéctelo al puerto
de control RS-232C del ordenador.
2 USB RELACIONAR (Propósito del servicio)
Este conector es para la actualización del rmware.
3 COMPUTER IN
Conecte la señal de entrada de imagen (analógica) a esta clavija.
4 S-VIDEO
Conecte una salida de S-Vídeo del equipo de vídeo a esta clavija.
5 VIDEO
Conecte la salida de vídeo compuesto del equipo de vídeo a esta clavija.
6 AUDIO IN
Conecte una salida de audio del equipo de vídeo a esta clavija.
2 3
5 64
1
Puertos de conexión
