ViewSonic Corporation’s QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
DISPLAY Type 0.65" Digital Micromirror Device (DLP™)
Resolution WXGA 1280x800 (native)
Lens 1.2x Manual optical zoom / manual optical focus
Keystone Vertical digital keystone correction (+/- 40º)
Size 30 – 300 in. / 0.76 – 7.6 m (diagonal)
Throw Distance 3.9 – 32.8 ft. / 1.2 – 10 m
Throw Ratio 1.47~1.83:1
Lamp 240 watt
Lamp Life 3500 / 5000 / 7000 hours* (Normal / Eco-mode / DynamicEco)
Brightness 3500 Lumens
Contrast Ratio 15,000:1 (w/ DynamicEco
™
)
Aspect Ratio 16:10 (native)
Color Depth 30 bits, 1.07B Color (10+10+10)
Color Wheel 5-seg RGBYW / 7200rpm
INPUT SIGNAL Computer and Video NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60),
SECAM (B, D, G, K, K1, L), SD 480i and 576i, ED 480p and
576p, HD 720p, 1080i, 1080p
Frequency Fh: 31–100KHz, Fv: 24–120Hz
COMPATIBILITY PC VGA to 1600x1200 UXGA
Mac
®
Up to UXGA (may require MAC adaptor)
CONNECTOR RGB Input 15-pin mini D-sub (x2)
RGB Output 15-pin mini D-sub
Digital Input HDMI
Component Input 15-pin mini D-sub (x2, shared with RGB)
Composite Input RCA jack
S-Video Input 4-pin mini-DIN
Audio Input 3.5mm mini jack (x2)
Microphone Input 3.5mm mini jack (shared with Audio 2)
Audio Output 3.5mm mini jack
Control RS-232 (DB-9)
LAN RJ45
USB Type A (card reader and wireless dongle)
Type B (mouse control and service)
Mini Type B (USB display)
AUDIO Speaker 16-watt (x1)
POWER Voltage 100~240VAC (Auto Switching), 50/60Hz (universal)
Consumption 305W (typ) / <0.5W (stand-by mode)
CONTROLS Basic Power, keystone/arrow keys, left, menu/exit, right, source,
mode/enter, auto
OSD Picture, Video/Audio, Setting, Option, Language, Information
(See user guide for full OSD functionality)
OPERATING Temperature 32ºF–104ºF (0ºC–40ºC)
CONDITIONS Humidity 10%–90% (non-condensing)
Altitude 0~6,000 ft (1,800m), operational up to 10,000 ft (3,048m)
NOISE LEVEL Normal / Eco-mode 34dB / 32dB
DIMENSIONS Physical 11.6 x 4.5 x 8.6 in. / 294 x 113 x 219 mm
(W x H x D) Packaging 13.9 x 12.2 x 7.1 in. / 352 x 310 x 180 mm
WEIGHT Net 4.7 lbs. / 2.1 kg
Gross 7.4 lbs. / 3.3 kg
REGULATIONS CB, UL/cUL, FCC-B, NOM, KC, REACH, ErP, SVHC
UL-Argentina, PSB, C-tick, SASO, CE, GOST-R,
CCC, RoHS, WEEE, UkrSEPRO
PJD6544w
PJD6544w projector, power cable, VGA cable, remote control with batteries, Quick Start Guide,
ViewSonic Wizard DVD (with User Guide).
What's in the box?
Optional Accessories
Replacement Lamp ........................................RLC-084
3D Active Shutter Glasses......................... PGD-series
Audio In / Out
AC Power
Monitor Out
S-Video/Video Inputs
Type B USB
(Mouse Control &
Service)
RGB/Component
Video Inputs
3D Blu-ray Ready HDMI
HDMI delivers the highest picture and sound quality without degradation.
Equipped with the latest HDMI, ViewSonic's PJD6544w projector can display
3D images directly from 3D Blu-ray
®
players—perfect for connecting to any
HDMI-enabled devices such as PCs, laptops, tablets, and media players.
Focus Ring
Control Panel
IR Remote Sensor
Projection Lens
Elevation Foot
Kensington
®
Lock Slot
Projection Distance
Screen Size (16:10)
Diagonal
Feet
4.2 - 5.2
8.3 - 10.3
12.5 - 15.5
15.6 - 19.3
20.8 - 25.8
26.0 - 32.2
31.2 - 38.6
Inches
40
80
120
150
200
250
300
Meters
1.3 - 1.6
2.5 - 3.1
3.8 - 4.7
4.7 - 5.9
6.3 - 7.8
7.9 - 9.8
9.5 - 11.8
Meters
1.0
2.0
3.0
3.8
5.1
6.4
7.6
Zoom Ring
Type A USB
(For card reader and
wireless dongle)
LAN RJ45
HDMI
Superior Color Performance
BrilliantColor
™
technology provides multi-color processing to produce
stunning, vibrant colors. Unlike other technologies that use just 3 primary
colors to produce the image (such as LCD), the PJD6544w uses up to
5 separate colors. The sophisticated 5-segment color wheel enhances the
yellow color performance that is key to accurate and vivid color reproduction.
Mini Type B USB
(USB Display)
RS-232
Plug n’ Play USB Display
Project your presentations using a quick and simple plug-and-play USB
connection without running a bulky VGA cable. Plug n’ Play also features
automatic resolution detection for the best imaging experience.
Networkable WXGA
Widescreen Projector
Long Lamp Life up to 7000 Hours
New and advanced lamp technology extends the projector’s lamp life up
to 7000 hours*, resulting in huge savings on lamp replacement costs.
*7000 hours is estimated under DynamicEco mode.
