ViewSonic VA703b-4 - Recommended Spare Parts List

ViewSonic Corporation 56
7. Recommended Spare Parts List
Confidential - Do Not Copy VA703b-4_VA703m-4
ViewSonic Model Number:VS11366
Serial No. Prifix:
QAN Rev: 1a
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number
#
1 Accessories:
AC POWER CORD 美規 22AWG A-00006505 W402221509531
2
MAIN BOARD ASSY B-00006501 XLM191A040002
3
KEY BOARD ASSY B-00006502 XLM191A050001
4
POWER BOARD+INVERTER BOARD ASSY B-00006503 XLM1700390010
5
BEZEL ASSY LM/MR17I-AA C-00006508 XLM171A100004
6
HOUSING ASSY LM/MR17I-AA C-00006509 XLM171A110002
9
BASE ASSY(midnight gray) C-00006583 XLM171A280003
7
VGA CABLE 30AWG UL20276 CB-00006504 W0926418AQ951
8
FFC CY050408001 - Flat Cable CB-00006506 W47A103015001
10
Documentation:
Safety Label DC-00006500 F102506171A02
11
Hardware:
BRACKET ASSY(midnight gray
)
HW-00006511 XLM171A200002
12
POLYETHYLENE-L EPS P-00006584 F20133171A002
13
POLYETHYLENE-R EPS P-00006585 F20143171A002
14
PLASTIC BAG PE P-00006586 F300250000070
15
CARTON C(K4K) LM/MR17I-AA P-00006587 F400718171A02
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2: All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic
Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
PC Board
Assembly:
RECOMMENDED SPARE PARTS LIST (VA703b-4)
Description
Packing Material:
Cables:
Cabinets:
ViewSonic Model Number:VS11366
Serial No. Prifix:
QAN Rev: 1b
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number#
1
Accessories: AC Power Cord A-00006505 W402221509531
2
Main Board B-00006501 XLM191A040002
3
Key Board B-00006502 XLM191A050001
4
Power Board + Inverter Board B-00006503 XLM1700390010
5
Power Board + Inverter Board Rev. 1 Added on 09/28/06 B-00008053 XLM1700390015-SF
6
Front Panel C-00006508 XLM171A100004
7
Back Cover C-00006509 XLM171A110002
8
Back Cover (midnight gray RGB ONLY REV:2) Added on 09/28/06 C-00008129 XLM171A110006
9
Base Assembly (midnight gray) C-00006583 XLM171A280003
10
VGA Cable 30AWG UL20276 (Video Cable) CB-00006504 W0926418AQ951
11
Flat Cable - FFC CY050408001 CB-00006506 W47A103015001
12
Flat Cable - FFC CY050408001 P=1.0mm 30PIN L150mm Added on 09/28/06 CB-00008033 W47A103015003
13
Documentation: Safety Label DC-00006500 F102506171A02
14
LCD Panel M170E5-L09 17" SXGA CMO Added on 09/28/06 E-00005791 E34722170SC01
15 LCD Module SVA170SX01TB 17" SVA Panel Lead Free
Added on 09/28/06 E-00008055
E34S22170S001-A
16
Bracket (midnight gray) HW-00006511 XLM171A200002
17
Bracket (midnight gray) for CMO Added on 09/28/06 HW-00008013 XLM191A200001
18 Bracket (black) LM/MR19I-AAA For SVA
Added on 09/28/06 HW-00008014 XLM191A200002
19
POLYETHYLENE-L EPS P-00006584 F20133171A002
20
POLYETHYLENE-R EPS P-00006585 F20143171A002
21
PLASTIC BAG PE P-00006586 F300250000070
22 Generic Foam Set
P-00001347 30833
23 Generic Box
P-00002515 20653
P-00006587
F400718171A02
P-00008146 F4007K4171A01
Remark 1: Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2:
Removed & Replace Part
on 09/28/06
24
Packing Material:
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by ViewSonic Corporation. This is to eliminate
repeated cross checks of each item between this version and prior versions.
Cables:
Electronics:
Hardware:
Craft Box - LM/MR17I-AA
RECOMMENDED SPARE PARTS LIST (VA703b-4)
Description
Cabinets:
PC Board Assembly:
