ViewSonic Model Number: VS11366
Rev: 1a
Item
ViewSonic P/N
Ref. P/N Description Location Universal number# Q'ty
1 N/A E015-006-W (10mm*14mm) Bird logo 1
2 N/A E015-016-1-W VIEWSONIC38MM 1
3 N/A E34M02170J001 LCD MODULE MT170EN01 1280×1024[SX] 17" LVDS INNOLUX 1
4 N/A F0004171AK001 Quick Install Manual LM/MR17I-AAA L190*W127mm for viewsonic REV:0 1
5
N/A
F0010171A3001
base attachment procedure LM/MR17I-AAA ENGLISH L190*W127mm for
viewsonic VA703 REV:0
1
6 N/A F001219043001 LM/LM1904 ENGLISH L210*W148mm for viwesonic REV:0 1
7 N/A F101415170401 MARK LM/LM1704 L11*W11mm energy star 1
8 DC-00006500 F102506171A02 Safety Label LM/MR17I-AA L89.5*W49.5mm for viewsonic(VA703b) 1
9 DC-00005754 F103010LM0001 Blank Label LM/MONITOR L43*W10mm 1
10 N/A F103015170401 Blank Label LM/LM1704 L50*W25mm 1
11 N/A F103915170401 CARTON LABEL(UPC) LM/LM1704 L76*W76mm FOR VIEWSONIC 1
12 N/A F103915171A01 CARTON LABEL LM/MR17I-AAA L89*W58mm forviewsonic 8ms 1
13 N/A F104515170401 RATING LABEL LM/LM1704 L7*W7mm for Viewsonic 1
14 P-00006584 F20133171A002 POLYETHYLENE-L EPS LM/MR17I-AAA L133*W139*H465mm 1
15 P-00006585 F20143171A002 POLYETHYLENE-R EPS LM/MR17I-AAA L133*W139*H465mm 1
16 P-00006586 F300250000070 PLASTIC BAG PE L610*W510*T0.04mm 1
17 N/A F400714171A01 CARTON K=K LM/MR17I-AAA L295*W148*H485mm 0.056
18 P-00006587 F400718171A02 CARTON K=K(K4K) LM/MR17I-AA L440*W147*H485mm for 1
19 N/A F401918171A04 PAPER COVER C LM/MR17I-AAAL1181*W1034*H80mm 0.028
20 N/A F50206171A003 PALLET GLUE LM/MR17I-AAAL1181*W1034*H120mm 0.014
21 N/A F801190000016 CD Manual LM/MR17I-AA VIEWSONIC VA703b INNOLUX REV:0 1
22 N/A F900181000001 PE LIMPID W500*T0.03mm1500m/ROLL PACKTHREAD PP WHITE 0.000156
23 N/A F9008G2000002 PACKTHREAD PP WHITE W14.5mm*T0.8mm 1300m/ROLL 0.000275
24 N/A M101082807401 SCREW COPPER Φ2.8*L7mmWITH NICKEL 2
25 N/A M105243005401 SCREW MACHINE (Binding) Φ3.0mm L5mmNICKEL 15
26 N/A M105244006401 SCREW BINDING Φ4.0*L6mm WITH NICKEL AD WASHER 1
27 N/A M108224008401 MACHINE SCREW Φ4.0*L8mm NICKEL 4
28 N/A M115233008401 SCREW TA PW Φ3.0*L8.0mm NICKEL Washer(Φ10.0mm) 2
29 N/A M621700LM0360-A Main Bracket SECC LM/MR17I-AAA REV:0 1
30 N/A P36AKAF010001 MYLAR L350 X W290 X T0.12MM 1
31 N/A P440700450002 RUBBER CUSHION Φ7.0*H4.5mm GRAY 4
32 N/A P705A997LM030-A Back Cover ABS HB GRAYINJECTION LM/MR17I-AA REV:0 1
33
N/A
V300800000001
GLUE 50g/PES
﹕- 60℃~+200℃)
0.01
34 N/A V5004AP150201 ADHESIVE TAPE L25000*W15*T0.25mm 25m/ROLL(YW0910300002) 0.012
35 N/A V5005A5080101 ADHESIVE TAPE L50000*W8*T0.1mm 0.006
36 N/A V501275024801 ADHESIVE TAPE L75m*W48*T 0.045mm FOR VIEWSONEC 0.006
37 N/A V900505020003 AL FOIL L50×W30×T0.10mm 1
38 N/A V900505030001 AL FOIL L100xW40xT0.07mm 1
39 N/A V900505030007 AL FOIL L100xW30*T0.35mm(Y78400004G*1) 4
40 CB-00006504 W0926418AQ951 VGA CABLE 30AWG UL20276 L1800mm 15PIN BLACK 1
41 A-00006505 W402221509531 AC POWER CORD UL 22AWG L150cm BLACK YISHENG 1
42 CB-00006506 W47A103015001 FFC WIRE CY050408001 P=1.0mm 30PIN L150mmHUNG FU 1
43 N/A W47B101035001 FFCWIRE FFCC0605T2350EC P=1.0mm 10PIN L350mm HANQUAN 1
44
B-00006503
XLM1700390010
POWER BOARD+INVERTER BOARD ASSY PI-SB03 24V+5V LM/17''/19''
LCD MONITOR FOR VIEWSONIC
1
45 C-00006508 XLM171A100004 BEZEL ASSY LM/MR17I-AA BEZEL(midnight gray)+BUTTON(SILVER) 1
46 N/A P727A997LM030-C BEZEL ABS HB GREY PRINT LM/MR17I-AA REV:0 1
47 N/A P763P398LM020-B FUNCTION BUTTON PC SILVER LM/MR17I-AAA REV:0 1
48 N/A XLM171A110003 HOUSING ASSY LM/MR17I-AA midnight gray RGB ONLY REV:1 1
49 N/A M105243006401 MACHINE SCREW Bouding Φ3.0*L6mm NICKEL 2
50 N/A M410810130001 VASA BKT T=0.8mm SECC 4
51 N/A M627700LM0240-E Holder SECC LM/MR17I-AAA L114*W29.6*H6.0*T1.5mm REV:0 1
52 N/A P728A997LM020-A HOUSING ABS HB GREY INJECION LM/MR17I-AA RGB ONLYREV:0 1
53
N/A
V300800000001
GLUE 50g/BOTTLE
﹕-60℃~+200℃)
0.01
54 HW-00006511 XLM171A200002 BRACKET ASSY(midnight gray) LM/MR17I-AA bracket+hinge+screw 1
55 N/A M155234008401 SCREW Φ4.0*L8mm NICKEL WITH WASHER 3
56 N/A M701900LM0140-K Hinge SPCC WITH NICKEL LM/MR17I-AAA FRONT 5° REAR 20°REV:0 1
57 N/A P711A997LM010-A Bracket ABS HB GRAY INJECION LM/MR17I-AA REV:0 1
58 C-00006583 XLM171A280003 BASE ASSY(midnight gray) LM/MR17I-AA BASE+RUBBER 1
59 N/A P612012010001 RUBBER FOOT ROUND Φ12*T2mm BLACK 6
60 N/A P74AA997LM010-A BASE ABS HB GRAY INJECION LM/MR17I-AA REV:0 1
61 N/A XLM171A380001 SHIELD ASSY LM/MR17I-AAA SHIELD+MYLAR 1
62 N/A M711200LM0130-A SHIELD SPTE T=0.3mm LM/MR17I-AAA REV: 1
63 N/A P369579010001 MYLAR L95*W79.5*T0.1mm WHITH ADHESIVE 1
64 B-00006501 XLM191A040002 MAIN BOARD ASSY LM/MR19I-AA 1
65 N/A A01F241615A21 IC EEPROM AT24C16 2500ns ATMEL SOIC-8 2K*8 (SMD) 1
66
N/A
A03D111703G03
IC LINEAR IC VOLTAGE REGULATOR GL1117A-3.3 (INPUT4.8~12V
OUTPUT 3.3V) SOT-223 GTM LeadFree (SMD)
1
67 N/A A03D111703A54 IC LINEAR VOLTAGE REGULATOR AP1117E33A SOT-223 ANACHIP 1
68 N/A A07TV51202M02 IC MCU MTV512GMG 64K MYSON LQFP-48P Lead Free (SMD) 1
69 N/A A08D2023R2001 IC ASIC/SCALER RTD2023L PLCC-48P REALTEK Lead Free(SMD) 1
70 N/A BLM19VAM10112 BARE PCB LM/MR19V-AAAD MAIN BOARD 2SIDES FR-4 T1.2mm 1
71 N/A C02205003C111 CAP MLCC NPO 5pF 50V ±0.25%(C) 0603 TAPPING (SMD) 3
72 N/A C02210003J111 CAP MLCC NPO 10pF 50V ±5% 0603 TAPPING (SMD) 2
73 N/A C02212003J111 CAP MLCC /NPO 12PF 50V ±5%(J) 0603 TAPPING (SMD) 1
74 N/A C02222003J111 CAP MLCC /NPO 22PF 50V ±5%(J) 0603 TPPING (SMD) 3
75 N/A C02310501K111 CAP MLCC X5R 1uF 16V ±10% (K) 0603 TAPING (SMD) 1
76 N/A C02410302K111 CAP MLCC X7R 10nF/25V ±10%(K) 0603TAPPING (SMD) 1
BOM LIST(VA703b-4)
ViewSonic Corporation 58
Confidential - Do Not Copy VA703b-4_VA703m-4
