ViewSonic Model Number: VS11366
Rev: 1a
Item ViewSonic # Ref. P/N Description Location Universal number# Q'ty
1 N/A E015-006-W (10mm*14mm) Bird logo 1
2 N/A E015-016-1-W VIEWSONIC38MM 1
3 N/A E231080150009 SPEAKER 3717CP15 OBLONG 8Ω1.5W R/L450mm 1
4 N/A E34M02170J001 LCD MODULE MT170EN011280×1024[SX] 17" LVDSINNOLUX 1
5 N/A F0004171AK001 Quick Install ManualLM/MR17I-AAAL190*W127mm for 1
6 N/A F0010171A3001
base attachment procedureLM/MR17I-AAA ENGLISHL190*W127mm for
viewsonicVA703 REV:0
1
7 N/A F001219043001 LM/LM1904 ENGLISHL210*W148mm for viwesonic REV:0 1
8 N/A F101415170401 MARK LM/LM1704L11*W11mm energy star 1
9 N/A F102506171A01 Safety Label LM/MR17I-AAA L89.5*W49.5mmfor viewsonic(VA703m) 1
10 DC-00005754 F103010LM0001 Blank Label LM/MONITOR L43*W10mm 1
11 N/A F103015170401 Blank Label LM/LM1704 L50*W25mm 1
12 N/A F103915170401 CARTON LABEL(UPC) LM/LM1704L76*W76mm FOR VIEWSONIC 1
13 N/A F103915171A01 CARTON LABEL LM/MR17I-AAA L89*W58mm forviewsonic 8ms 1
14 N/A F104515170401 RATING LABEL LM/LM1704 L7*W7mm forViewsonic 1
15 P-00006584 F20133171A002 POLYETHYLENE-L EPSLM/MR17I-AAAL133*W139*H465mm 1
16 P-00006585 F20143171A002 POLYETHYLENE-R EPSLM/MR17I-AAAL133*W139*H465mm 1
17 P-00006586 F300250000070 PLASTIC BAG PEL610*W510*T0.04mm 1
18 P-00006591 F400714171A01 CARTON K=K LM/MR17I-AAAL295*W148*H485mm 0.056
19 N/A F400718171A03 CARTON C(K4K) LM/MR17I-AAA L440*W147*H485mm 1
20 N/A F401918171A02 PAPER COVER C LM/MR17I-AAAH1200*W885*H100mm 0.017
21 N/A F401918171A04 PAPER COVER C LM/MR17I-AAAL1181*W1034*H80mm 0.028
22 N/A F50206171A003 PALLET GLUE LM/MR17I-AAAL1181*W1034*H120mm 0.014
23 N/A F801190000017 CD MANUAL LM/MR17I-AAA VIEWSONICINNOLUX REV:0 1
24 N/A F900181000001 PE LIMPID W500*T0.03mm1500m/ROLL PACKTHREAD PP WHITE 0.000156
25 N/A F9008G2000002 PACKTHREAD PP WHITEW14.5mm*T0.8mm 1300m/ROLL 0.000275
26 N/A M101082807401 SCREW COPPER Φ2.8*L7mmWITH NICKEL 2
27 N/A M105243005401 SCREW MACHINE (Binding) Φ3.0mm L5mmNICKEL 15
28 N/A M105244006401 SCREW BINDING Φ4.0*L6mm WITH NICKEL AD WASHER 1
29 N/A M108224008401 MACHINE SCREW Φ4.0*L8mm NICKEL 4
30 N/A M115233008401 SCREW TA PW Φ3.0*L8.0mm NICKEL Washer(Φ10.0mm) 2
31 N/A M621700LM0360-A Main Bracket SECC LM/MR17I-AAA REV:0 1
32 N/A P36AKAF010001 MYLAR L350 X W290 X T0.12MM 1
33 N/A P392411A00001 SPEAKER SPONGE L24.5*W11*T10mm L/R 25°(VA703) 4
34 N/A P440700450001 RUBBER CUSHION Φ7.0*H4.5m BLACK
35 N/A P705A995LM020-A Back Cover ABS HB BLACK LM/MR17I-AAA REV:0 1
36 N/A V300800000001
GLUE 50g/PES (﹕- 60℃~+200℃)
0.01
37 N/A V5004AP150201 ADHESIVE TAPE L25000*W15*T0.25mm 25m/ROLL(YW0910300002) 0.012
38 N/A V5005A5080101 ADHESIVE TAPE L50000*W8*T0.1mm 0.006
39 N/A V501275024801 ADHESIVE TAPE L75m*W48*T 0.045mm FOR VIEWSONEC 0.006
40 N/A V900505020003 AL FOIL L50×W30×T0.11mm S
41 N/A V900505030001 AL L100xW40xT0.07mm 1
42 N/A V900505030007 AL FOILL100xW30*T0.35mm(Y78400004G*1) 4
43 CB-00005758 W0026918A0142 AUDIO CABIE 26AWG UL2547L=1800mm 6C BLACK(N65B80-1800) 1
44 CB-00006504 W0926418AQ951 VGA CABLE 30AWG UL20276L1800mm 15PIN BLACK 1
45 A-00006505 W402221509531 AC POWER CORD UL 22AWG L150cm BLACK YICHENG 1
46 CB-00006506 W47A103015001 FFC Wire CY050408001 P=1.0mm 30PIN L150mm HUNG FU 1
47 CB-00006588 W47B101035001 FFC Wire FFCC0605T2350EC P=1.0mm 10PIN L350mm Hanquan 1
48 B-00006503 XLM1700390010
POWER BOARD+INVERTER BOARDASSY PI-SB03
24V+5VLM/17''/19'' LCD MONITORFOR VIEWSONIC
1
49 N/A XLM171A100003 BEZEL ASSY LM/MR17I-AAABEZEL+BUTTON SILVER 1
50 N/A P727A998LM010-H BEZEL ABS HB SILVER PRINT LM/MR17I-AAAREV:0 1
51 PL-00006589 P763P398LM020-B FUNCTION BUTTON PC SILVER LM/MR17I-AAA REV:0 1
52 N/A XLM171A110004 HOUSING ASSY LM/MR17I-AAABLACK RGB+AUDIO REV:1 1
53 N/A M105243006401 MACHINE SCREW Bouding Φ3.0*L6mm NICKEL 2
54 N/A M410810130001 VASA BKT T=0.8mm SECC 4
55 N/A M627700LM0240-E Holder SECC LM/MR17I-AAA L114*W29.6*H6.0*T1.5mmREV:0 1
56 N/A P728A995LM120-A HOUSING ABS HB BLACK INJECION LM/MR17I-AAARGB+AUDIO 1
57 N/A V300800000001
GLUE 50g/BOTTLE (﹕-60℃~+200℃)
0.01
58 N/A XLM171A200003 BRACKET ASSY LM/MR17I-AAAbracktet+hinge_bkt+screwBLACK 1
59 N/A M155234008401 SCREW Φ4.0*L8mm NICKEL WITH WASHER 3
60 N/A M701900LM0140-K Hinge SPCC WITH NICKEL LM/MR17I-AAA FRONT 5° REAR 20° 1
61 N/A P711A995LM030-A Bracket ABS HB BLACK INJECTION LM/MR17I-AAA REV:0 1
62 N/A XLM171A280002 BASE ASSY LM/MR17I-AAABASE+RUBBER BLACK 1
63 N/A P612012010001 RUBBER FOOT ROUND Φ12*T2mmBLACK 6
64 N/A P74AA995LM100-A BASE ABS HB BLACK INJECTION LM/MR17I-AAA REV:0 1
65 N/A XLM171A380001 SHIELD ASSY LM/MR17I-AAASHIELD+MYLAR 1
66 N/A M711200LM0130-A SHIELD SPTE T=0.3mm LM/MR17I-AAA REV: 1
67 N/A P369579010001 MYLAR L95*W79.5*T0.1mmWHITH ADHESIVE 1
68 N/A XLM191A040001 MAIN BOARD ASSY LM/MR19I-AAA 1
69 N/A A01F241615A21 IC EEPROM AT24C16 2500nsATMEL SOIC-8 2K*8 (SMD) 1
70 N/A A03D111703G03
IC LINEAR IC VOLTAGEREGULATOR GL1117A-3.3(INPUT 4.8~12V
OUTPUT 3.3V)SOT-223 GTM LeadFree (SMD)
1
71 N/A A03D111703A54 IC LINEAR VOLTAGE REGULATORAP1117E33A SOT-223 1
72 N/A A07TV51202M02 IC MCU MTV512GMG 64K MYSONLQFP-48P Lead Free (SMD) 1
73 N/A A08D2023R2001 IC ASIC/SCALER RTD2023LPLCC-48P REALTEK Lead Free(SMD) 1
BOM LIST (VA703m-4)
ViewSonic Corporation 60
Confidential - Do Not Copy VA703b-4_VA703m-4
