TV
OUT+7dB
OUT+7dB
12 ~16VDC
200mA
INPUT
If your setup is not close to the signal source, it is recommended to install a
indoor video amplifier to improve the signal. Indoor video amplifiers are
available at your local electronics store.
Note:
Omit the splitter connection in the following figure if there is no cable modem
present in your setup.
Two way splitter
Cable modem
Indoor Amp.
Cable or antenna
outlet
VGA output
from PC
(PC)
The best location of an
indoor amplifier is near a
television.
2.2.3 Extended wiring
VCR / Cable box
AC outlet
9
