2.2.2 Connect to remote signal
If you must connect to a cable outlet or antenna located someplace other
than your setup area, use the following examples:
Cable or antenna
outlet
TV
Adapter
Two way splitter
Camera
Video game
RCA A/V cable
S-VIDEO cable
VCR / Cable box
DVD/VCR/LD/ IRD
Speaker
RGB output
from PC
Monitor
Audio output
from PC
WARNING: Turn off all devices before you begin.
Audio/Video connection:
For audio connection, use RCA audio(L+R) connector. For video connection, use
an RCA video connector or as S-Video connector.
Disregard PC connections if you are only connecting your VB50HRTV to a monitor.
8
Installation
