ViewSonic Corporation Confidential - Do Not Copy
7
16. 1024 x 768 @ 75Hz, 60.0kHz Yes Yes
17. 1280 x 1024 @ 60Hz, 63.4kHz Yes Yes
18. 1280 x 1024 @ 75Hz, 79.97kHz Yes Yes
19. 1400x 1050 @ 60Hz, 65.3kHz Yes Yes
Primary Presets
“1400 x 1050” @ 60Hz
User Presets
Number of User Presets (recognized timings) Available: 10 presets total in FIFO configuration
Changing Modes
● Maximum Mode Change Blank Time for image stability : 3 seconds (Max), excluding “Auto Adjust” time
● Under DOS mode (640 x 350, 720 x 400 & 640 x 400), it should recall factory setting when execute “Auto Adjust”
● The monitor needs to do “Auto Adjust” the first time a new mode is detected
(see section “0-Touch™ Function Actions”)
● While running Change Mode, Auto Adjust or Memory Recall, the image shall blank
2.6 FRONT PANEL CONTROLS AND INDICATORS
Front Panel Hardware Controls
Power Switch (Front Head) Power Control, soft Power Switch.
Power LED (Front Head) Green – ON
Orange – Active Off
Dark = Soft Power Switch OFF
Front Panel Controls (Head)
[;X] [ 1 ] [▲] [▼] [ 2 ] [
]
[
] Power
[;X]Audio mute on/off
[ 1 ] BUTTON 1
[▲] UP ARROW BUTTON
[▼] DOWN ARROW BUTTON
[ 2 ] Button 2
Note: Power Button, Button 1, Button 2, and Mute Button must be
one-shot logic operation.
Reaction Time OSD must fully appear within 0.5s after pushing Button 1
Short Cuts Function from the button(s)
[1] Main Menu
[2] Input selection
[▼] Brightness adjust
[▲] Contrast adjust
[▼]+ [▲] recall both of Contrast and Brightness to default
[1]+[2] Toggle 720x400 and 640x400 mode when input 720x400 or 640x400
[1] + [▼] Power Lock
[1] + [▲] OSD Lock
Remark : All the short cuts function are only available while OSD off
VG2030m-1
To Next Page
