ViewSonic VG2021m-1 User Manual

ViewSonic Model Number: VS11234
Rev: 1a
Serial No. Prefix: QGZ
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
1 HW-00000553 42A9930008
SCREW,3,P=0.5 mm,L=4 mm,Pan Head,Phillips Cross Recess,Hama Naka Motogawa Hama
Naka Shoukin Shiho Shin Yee Shye Ching,Green I
15
2 HW-00006041 42A9940007
SCREW,4,P=0 mm,L=11.8 mm,Hexagon Stand Off,Socket,ShihoShin YeeShye Ching Hama
Naka Motogawa,Green I
4
3 HW-00004042 42-D000649
SCREW,M4,P=0.7 mm,L=8 mm,Round Head,Phillips Cross Recess,plate color
Zn,Screw_with_Washer,Shye Ching Hama Naka Motogawa Shin Yee,head D8,Green I
1
4 C-00005673 41-D002955
Cover AD Assy,A190A2,secc,Jiin Ming Kunshan Jincheng_Base Assy CLT
Ningbo_Metal,Green II
1
5 B-00006040 27-D004260
Lips With Audio,DAC-12M033 AF,02 A,12 V/0.7 A,5 V/3 A,4L,5 mA,2650 V,Delta
Dongguan_LIPS,Green I
1
6 C-00005685 41-D004344 Metal Frame Front,A201P1,SECC t=0.6mm,Fomgder/Chia Chang Suzhou,Green II 1
7 N/A 44-D008021 Backlight Unit,A201P1,CLT_BL,L-type lamp,Green II 1
8 CB-00005677 32-D008152
FFC,0.5x36x117xD(3.5/3.5/5/5),36 Pins,Tennsure Young Shin,PCBA_X to
PCBA_AD,package AL foil,A201P1,Green I
2
9 B-00008011 35-D008184
PCBA for ,A190A2-A02-H,A190A2-A02-H-S1,1206-05,Rev.04,USI ITC Gigabyte,ODM,Cost
Down,Green II
1
10 N/A 36-D001339 Driver IC,Scan,A170E1,HX8633CPD400,256Channel,Himax,Green II 4
11 N/A LXK109XXX1 20.1” TN Asahi 0.7mm & CMO CF with Photo Spacer for ODF Process (Panel Base) 1
12 N/A 73-D012894
ACF,COG,AC-8409J-23,100000 mmx1.5 mm,Hitachi Chemical,Hitachi COG_ACF AC-
8409J-23
0.00332
13 N/A 7344191017 ACF,AC-4251FY-16,100M/RL,Green I 0.0044
14 N/A 36-D004403
Driver IC,COF,Data,A201P1-P01-H,HX8018-A050CBB9,SOF,6
bit,432Channel,Himax,RoHS,Green I
10
15 N/A 73-D002676 ACF,PCB,AC-9825R-35,100000 mmx1.5 mm,Hitachi Chemical,PCB-ACF,Green I 0.0044
16 N/A 35-D004526 PCBA for ,A201P1-H,A201P1-P01-H-X,1101-01,Rev.02,ITC USI,ODM,Green II 1
17 N/A 7349951002 Silicone,TORAY/-9187L,330g 0.5
18 N/A 10-D010697
Software (BIOS),A201P1,20P1LS1003,VSC,Checksum(0x84F8),VSC 201
TSUM,DUAL,AUDIO,Green II
1
19 HW-00000555 42A9930014
SCREW,3,P=0.5 mm,L=6 mm,Pan Head,Phillips Cross Recess,Hama Naka Shoukin/Shye
Ching/Hama Naka Motogawa/Shin Yee, NA,Green I
4
20 HW-00000557 42A9930017
SCREW,3,P=1.27 mm,L=8 mm,Pan Head,Phillips Cross Recess,Shiho Shin Yee Shye
Ching,Green I
2
21 N/A 41-D007449 Support Plate,A201P1-H14,SECC,Jiin Ming,Green II 1
22 C-00005671 40-D007468 Rear Assy,A201P1-H14,Black(ABS-PA757-J01),Push Power,Audio-in+DVI-D,Green II 1
23 CB-00005675 32-D007466 FFC,862P051787A/CFC2108,6 Pins,Tennsure_FFC/Hung Fu,Green I 1
24 CB-00005676 32-D007464 FFC,862P051786A/CFC2109,15 Pins,Hung Fu/TennRich,Green II 1
25 B-00005704 35-D007990 PCBA for ,A201P1-P01-H,A201P1-P01-H-K2,1101-01,Rev.01,ITC USI,ODM,Green II 1
26 B-00005703 35-D007988 PCBA for ,A201P1-P01-H,A201P1-P01-H-K1,1101-01,Rev.01,ITC USI,ODM,Green II 1
27 C-00008140 40-D013516
Bezel Assy,A201P1-H08,ABS PA-757,Silver(TY4818A)/Black(M1077),Push Power,Green II
1
28 C-00008139 40-D013575 Cover Hinge Assy,A201P1-H08,ABS PA-757,Black(J01),Fuking,ViewSonic,Green II 1
29 C-00008141 40-D013661
Stand Seat Assy,A201P1-H08,Black,ViewSonic Display Limited,VSC P/N:C-00008081,Green
I
1
30 PL-00008032 73-D007951 Panel Protector Film,A201P1-H14,XG-536 t=0.1,Just Enter,Green I 1
31 DC-00008134 77-D013594
Safety Label for ,A201P1-H08,160 mmx30 mm,Kunshan Hwakuan Chang
Huang,VSC_VG2030m,Green II
1
32 N/A 77-D013596
SN Label for ,A201P1-H08,50 mmx25 mm,Chang Huang Kunshan
Hwakuan,VSC_VG2030m,Green II
1
33 N/A 7841795141 Corner Protector,paper,50 mmx50 mmx900 mm,Green I 0.083
34 P-00000595 7841919921
Bag,570 mmx600 mmx0.13 mm,Huang Jyii Suzhuo Hon Chuan Taiwan Hon
Chuan,Default,Green II
1
35 M-00000560 7345511002 Tape,A170E1-H0P,900 mmx50 mmx0 mm,Symbio,OPP 0.005
36 N/A 78-D003113
Pallet,A190E3-H02_acer,Wooden,(KD-HT),1209 mmx1066 mmx135 mm,Hua Sun
Paper/Shanghai Hang Wei/Ming Li,Green I
0.042
37 N/A 78-D004866
Corner Protector,Paper,M190E3,50 mmx50 mmx1400 mm,Jonin/NingBo Ming-Chan_EPS
T:3mm,Green I
0.17
38 N/A 78-D004868
Corner Protector,Paper,M201P1,50 mmx50 mmx800 mm,Jonin Kun Shan Zhong Yang
NingBo Ming-Chan_EPS T:3mm,Green II
0.083
39 P-00008137 78-D013578
Cushion,A201P1-H08,EPS,White,510 mmx285 mmx175 mm,Li Ta,PS_From (TOP),Green II
1
40 N/A 79-D013573 Shipping Package Information for ,A201P1-H08,ViewSonic 1
41 P-00008136 78-D013577
Cushion,A201P1-H08,EPS,White,510 mmx285 mmx175 mm,Li Ta,PS_Foam (Bottom),Green
II
1
42 DC-00008135 77-D013595
Carton Label for ,A201P1-H08,76.2 mmx76.2 mm,Chang Huang Kunshan
Hwakuan,VSC_VG2030m,Green II
1
43 DC-00008136 76-D013600
MENU for A201P1-H08,Complex,1C,Yi Ching Car Tong Kunshan,VSC_VG2030m CD-
ROM,Green II
1
44 P-00008138 78-D013593
Carton,A201P1-H08,520 mmx290 mmx560 mm,Chen Yi Paper Yuen Foong Yu Suzhou Chen
Yi Ningbo,VSC_VG2030m,Green II
1
45 DC-00008010 7741513161
SN Label for ,A150X1-T02,75 mmx40 mm,Chang Huang Car Tong Kunshan Kunshan
Hwakuan,Pallet Barcode Label,Green I
0.04
46 N/A 10-D013640
Software (EDID_D-SUB),A201P1,VSC4D1FA00,VSC,Checksum(50),VSC VG2030m Analog
Port,Green II
1
47 N/A 10-D013638
Software (EDID_DVI),A201P1,VSC4D1FD00,VSC,Checksum(9F),VSC VG2030m Digital
Port,Green II
1
48 CB-00000547 32F2818004 Accessory Cable,Audio,NONE,Black,Pins-Pins,Green I 1
49 CB-00004287 32F3018003 Accessory Cable,D-Sub,BLACK,Jceprocable,A150X2,Green I 1
50 A-00004047 32-D001922 Power Cord,VCTF 3G 0.75mm^2 CNS CT-08,Black,BSMI,1800 mm,I Sheng,GreenII 1
51 CB-00002083 32F0000004 Accessory Cable,DVI,Black,Jceprocable,DVI-D(M) TO DVI-D(M),S/L,W/2F,Green I 1
BOM LIST (VG2030m-1)
VG2030m-1
ViewSonic Corporation Confidential - Do Not Copy
66
