2-2. The Exterior of the Monitor
A. Front B. Left and Right
1
C. Rear
2 55
4
3 2
1. Control panel (Expanded in 3-1)
2. I/O port (input/output) This area
should include all I/O connection
options, as well as the power input
connector (Expanded in 2-4)
3. Kensington security slot (Expanded in
2-3 section G)
4. This is the VESA wall mounting area
on the back of the moitor*. For the
VESA wall mounting installation
steps, please see 2-3 section F for
additional instructions.
*VESA wall mount capability varies
depending on model: some models
will not have VESA wall mounting
capability.
5. Speaker
