ViewSonic Confidential Creation Date: 12/21/05
ViewSonic Corporation
Confidential - Do Not Copy VP2650wb-1
79
Rev: 1b
Serial No. Prefix: QV0
Item ViewSonic P/N Ref.P/N Description Q'ty
1 PL-00008223 Q00-A070282
ASSY BASE CJC VP2650W 1
2 C-00008763
6K.0D702.001
ASSY BZL ABS VX2640W
1
3 C-00008767
6K.0D703.001
ASSY RC ABS VX2640W
1
4 E-00008814
5F.LTFCP.011
LCDM26 CLAA260WU09 P CPT
1
5 N/A
6K.0D704.001
ASSY BKT SECC 1,0T VX2640W 1
6 B-00008898
5E.0DV02.001
PCBA SPS BD MI VP2650V 1
7 B-00008899
5E.0DV07.001
PCBA TRANSMITTER BD MI VP2650W 1
8 N/A
6K.0D705.001 ASSY SHD SECC 0,8T VX2640W
1
9 N/A
5E.0DV03.001 PCBA CTRL BD MI VP2650W
1
10 B-00008897
5E.0DV01.001 PCBA IF BD MI VP2650W CPT
1
11 B-00008900
5E.0DV15.001 PCBA USB BD MI VP2650W CPT
1
12 PL-00008224 Q00-A070281
ASSY HINGE CJC VP2650W
1
13 N/A
3A.0AB01.001 LOGO AL VSC VP2250
1
14 N/A
4K.0D701.001 MYLAR PET 565*356*0.1 VX2640W
1
15 N/A
4G.0D703.001 GASKET 80*5*3 VX2640W 2
16 N/A
8F.VZ526.6R0 SCRW TAP FLAT
_
EXT M4*6L ZN-
W
1
17 N/A
8F.VG434.6R0 SCRW TAP PH W/F M3*6 TP-S C-ZN 17
18 N/A
8F.205B4.019 SCRW MACH STEEL HEX #4-40 NI 4
19 N/A
8F.5A224.6R0 SCRW MACH FLAT M3*0.5P*6L NI 6
20 N/A
8F.5A422.2R4 SCRW MACH FLAT-P M282.4L C-ZN 3
21 N/A
8F.8A356.100 SCRW MACH FPH M4*10L B-ZN NYL 6
22 N/A
8F.5A356.100 SCRW MACH FH M4*10L B-10L B-ZN NYL 4
23 N/A
5K.0D702.002 WIRE 14/13P 1007#24 135MM 1
24 N/A
5K.0D704.001 WIRE 10/9P 1007#24 20MM 1
25 N/A
5K.0DV01.001 WIRE 16/12P 1007#24 70MM 1
26 N/A
5K.0D706.001 FFC CABLE 7/7P 486MM 1
27 N/A
5K.0D708.001 CABLE LVDS 30/30P 185MM 1
28 N/A
5K.0BW01.002 WIRE HARNESS 10P/9P 30MM 1
29 N/A N/A
VP-26 CLIP
(
D.B. P/N#KST1-0113-00
)
2
30 N/A N/A
Lock Pin
(
D.B. P/N#KSS2-0017-00
)
1
31 N/A N/A
Warrin
g
label
(
D.B. P/N#KSL1-0002-00
)
1
EXPLODED PARTS LIST (VP2650WB-1)
ViewSonic Model Number: VS11997
