ViewSonic VP2650WB - Recommended Spare Parts List

ViewSonic Corporation
Confidential - Do Not Copy VP2650wb-1
80
11. Recommended Spare Parts List
Rev: 1b
Serial No. Prefix: QV0
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number#
1
Accessories:
Cord/ Cable-125V WO/SH 1.8M US A-00008250 2G.01111.001
2 Control Board- Dual CPT B-00008809 6K.0D709.001
3 Interface Board SMD B-00008897 5E.0DV01.001
4 PCBA SPS BD MI VP2650 B-00008898 5E.0DV02.001
5 Transmitter Board B-00008899 5E.0DV07.001
6 USB Board B-00008900 5E.0DV15.001
7
Cabinets:
Front Panel C-00008838 6K.0DV01.001
8 Rear Cover C-00008839 6K.0DV02.001
9 Base Assembly
Removed on 05/20/08 C-00008840 6E.0DV02.001
10 Cable - DVI-D/DVI-D 1.8M CB-00008460 5K.05406.501
11 Video Cable - L/C H+V OD_5.5 1.8M CB-00008461 5K.L2H06.511
12 USB Cable 1.8M CB-00008521 5K.L1E03.501
13 Wire 10/9P 60MM CB-00008529 5K.0D704.001
14 Cable LVDS 30/30P 185MM CB-00008530 5K.0D708.001
15 FFC Cable 7/7P 467MM CB-00008531 5K.0D706.001
16 Wire 16/12P 1007#24 70MM CB-00008607 5K.0DV01.001
17 Quick Start Guide DC-00008668 4J.0AB01.001
18 CD-Rom DC-00008817 5B.0DV01.001
19
Electronic
LCD Panel M26 CLAA260WU09 P CPT E-00008814 5F.LTFCP.011
20 Carton P-00008931 4D.0DV01.001
21 EPS Foam - Front P-00008932 4G.0DV03.001
22 EPS Foam - Back P-00008933 4G.0DV04.001
23
Plastics:
Hinge Assembly - CJC Removed on 05/20/08 PL-00008328 6E.0DV01.001
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2:
RECOMMENDED SPARE PARTS LIST (VP2650WB-1)
Description
ViewSonic Model Number: VS11997
All revised RSPLs with newly added items or any change made should be highlighted and correlated with the ECN/ECR approved by
ViewSonic Corporation. This is to eliminate repeated cross checks of each item between this version and prior versions.
Packing
Material:
[Box,
Foam, Bags]
PC Board
Assembly: [All
PCBA]
Documentation:
[Quick Start
Cables: [All Cable
s
Serial No. Prefix: QV0 Rev: 1a
Item ECR/ECN ViewSonic P/N Ref. P/N Location Universal number#
1
Cabinets:
VS-VP135-026A
VP-Toscano 26" Base
(
Direct Bu
y
: S/I - CJC
)
C-00008591
YPL-A07028
0
2
VS-VP135-026A-B
VP-Toscano 26" Pedestal
(
Direct Bu
y
: S/I - CJC
)
PL-00008223 Q00-A070282
3
VS-VP135-026A-N
VP-Toscano 26" Neck Assembly
(
Direct Bu
y
: S/I - CJC
)
PL-00008224 Q00-A070281
Remark 1:
Above listed items are examples, supplier can expand the rows to add more necessary items.
Remark 2: All revised RSPLs with newly added items or any change made should be highlighted and correlated
with the ECN/ECR approved by ViewSonic Corporation. This is to eliminate repeated cross checks of
each item between this version and prior versions.
Plastics:
RECOMMENDED SPARE PARTS LIST ( VP2650WB-1 )
Description
VP-Toscano 26" Base
Direct Buy Part No: C-00008591
