INVERTER
In order to drive the CCFLs embedded in the panel module, there is a half bridge inverter to convert by
the controller.
The input 12V up to hundreds of AC voltage output.
The inverter is formed by symmetric in order to drive the separate lamp modules.
The input stage consists of a PWM controller, half bridge inverter, and switching MOSFET to convert
DC input into AC output.
The output stage consists of a tuning capacitor, coupling capacitor, transformer, push-pull MOSFET
pair to boost AC output up to hundreds of voltage.
And one resister is serial to lamp for output voltage feedback.
There are two signal to control the inverter which come from system.
Logic “high” level which send to P106 pin6 is turn on the inverter.
BRI signal control brightness by DC level which was integral from PWM signal.
