Inverter CKT Start
Check B+ +12V
Check CON6
Plug:Pin6 4.1V
Pin4 0~3.5V
Check Q6 Q7 Q9
I103 TSUM66AJ
Inverter Unit Fail
Check
ONBACKLITE
(LOW)
Power Unit Fail
END
END
OK
NO
NO
OK
OK
OK
NO OK
NO
