ViewSonic Model Number: VS10725
Rev: 1a
Serial No. Prefix: QCL
Item ViewSonic P/N Ref. P/N Location Universal number# Q'ty
1 DC-00005307 2002370009P GUARANT CARD VP930 QSG TINSE3194T8 6P82 1
2 P-00005325 2011091103P CARTON BOX VP930B-2 VS10725 TCO03 6P01 1
3 P-00005322 2012186700P POLYFOAM SPAKA6617T8F VP930B 6P20 1
4 P-00008025 2013054023P POLYETHY BAG 160*140MM T=0.5MM LDPE 5B03 2
5 P-00008026 2013054030P POLYETHY BAG VP930 LCD BAG SSAKH1356D8-T-B 6P60 1
6 P-00008027 2013054031P POLYETHY BAG VP930 UG BAG SSAKD0010-1-T 6P83 1
7 C-00005329 2022267401P CABI BACK GC0VD2626T8F...MGY 2C02 1
8 C-00005329 2022267501P CABI BACK GCABB1883T8F...MGY 2C01 1
9 N/A 2024272901P FRONT BEZEL GCABA2369T8F...MGY 1F01 1
10 C-00008033 2028262001P STAND GSTN-2957T8K...MGY 5B01 1
11 N/A 2044269101P FUNCTION KEY JKNBP2392T8F...MGY 1F03 1
12 N/A 2051353800P NAME PLATE VIEWSONIC BIRD LOGO H:8MM 1F04 1
13 N/A 2053756001P LED INDIC.-PWR HDECP2012TSF VP930 1F02 1
14 M-LB-0813-0528 2055103400P LABEL JK0936F WEN 6P52 1
15 N/A 2055170062P LABEL VP930B-2 VS10725 TCO03 6P50 1
16 M-LB-0813-0856 2055613379P LABEL VIEWSONIC CONTAINER LABEL 6P11 71
17 N/A 2055613441P LABEL VIEWSONIC 8ms STICKER 89X58mm 6P04 2
18 N/A 2055670083P LABEL VP930B-3 VS10725(M) AUO 6P02 1
19 N/A 2055690013P LABEL EnergyStar Sticker 11*11mm 6P06 1
20 N/A 2055690014P LABEL VP930 H1-POT TLAB-5657T8 6P13 1
21 N/A 2055690015P LABEL VP930 HIGHVOLTAGE TLABZ4916T8 6P14 1
22 N/A 2055690046P LABEL VP930B-3 VS10725 SMALL LABEL 6P05 1
23 M-LB-0813-0002 2056603050P SERIAL LABEL VIEWSONIC LCD SERIAL LABEL 6P51 1
24 N/A 2061456100P BUSHING PCUSG1647T8 VP930B 2C08 2
25 N/A 2061456200P BUSHING PCUSG1674T8 VP930B 2C09 1
26 N/A 2061456300P BUSHING PCUSG1687T8 VP930B 1F23 3
27 N/A 2061456400P BUSHING PCUSG1651T8--- 1F25 2
28 N/A 2061456500P BUSHING PISLS1177d8---- 1F26 1
29 N/A 2063302400P PROTECTOR PISL-1351T8 VP930B 6P23 1
30 N/A 2071881100P BRACKET,FIX LANGF2194T8---A VP930 2C07 4
31 N/A 2071881200P BRACKET,FIX LANGF206-3D8---B VP930B 2C04 1
32 N/A 2071881300P BRACKET,FIX LANGF2232T8 VP930B 1F17 2
33 N/A 2071979700P METAL FITTG LANGF2227T8 VP930B 1F16 1
34 N/A 2072458300P INSULATOR 12*10*1.5 94V0 ADHESIVE 1F28 1
35 N/A 2072461300P INSULATOR PISLV0262T8---- 1F27 1
36 N/A 2072461400P INSULATOR 12*10*1.0 94V0 ADHESIVE 1F29 1
37 N/A 2080006100P SCREW,SPE XBPSB40P10JS0 (M4*10) VP930B 5B02 4
38 N/A 2080006200P SCREW,SPE XBMSB30P06000 VP930B 2C03 4
39 N/A 2080006300P SCREW,SPE LBOSM1069DB VP930B 1F22 6
40 N/A 2080006500P SCREW,SPE XBMSB30P05000-- (M3*5) VP930B 1F20 4
41 N/A 2081440082P SCREW,(WASH) M4X8 P=0.7(TOOTH WASHER) 1F30 1
42 N/A 2082630042P SCREW M3*4 P=0.5 1F18 4
43 N/A 2082630042P SCREW M3*4 P=0.5 1F19 7
44 N/A 2082640082P SCREW M4*8MM P=0.5 1F24 1
45 B-00005310 2200501200P PC BOARD ASS'Y SMD RUNTP5655T8 (INVERTER) SAMPO U901 RB 1
46 B-00008021 2200501300P PC BOARD ASS'Y SMD RUNTP5663T8 (INVERTER) SAMPO U901 RA 1
47 B-00005311 2200501400P PC BOARD ASS'Y SMD RUNTP5654T8 (POWER/B) SAMPO U801 RA 1
48 B-00008020 2200501500P PC BOARD ASS'Y SMD RUNTP5656T8 (POWER/B) SAMPO U801 RB 1
49 N/A 2202525000P PCB MULTILAYER VP930-2 M/B FR4*2 120*110 U101 1
50 N/A 2202525100P PCB MULTILAYER VP930-2 K/B FR4*2 108*9 U701 1
51 E-00008011 2212090200P LCD PANEL M190EG01-V0 AUO V901 1
52 N/A 2251275096P RES,CHIP 1/10 RC 0603 1/10W 75 ohm F T R101 1
53 N/A 2251275096P RES,CHIP 1/10 RC 0603 1/10W 75 ohm F T R102 1
54 N/A 2251275096P RES,CHIP 1/10 RC 0603 1/10W 75 ohm F T R103 1
55 N/A 2251275096P RES,CHIP 1/10 RC 0603 1/10W 75 ohm F T R127 1
56 N/A 2251275096P RES,CHIP 1/10 RC 0603 1/10W 75 ohm F T R128 1
57 N/A 2251275096P RES,CHIP 1/10 RC 0603 1/10W 75 ohm F T R129 1
58 E-R-0405-6600 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R190 1
59 E-R-0405-6600 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R192 1
60 E-R-0405-6600 2253200096P RES CHIP 1/10W RC 0603 1/10W 0 ohm J T R204 1
61 E-R-0405-6409 2253210196P RES CHIP 1/10W RC 0603 1/10W 100 ohm J T L102 1
Description
BOM LIST (VP930b-3)
ViewSonic Corporation Confidential - Do Not Copy VP930-3_VP930b-3
50
