ViewSonic Model Number: VS10725
Rev: 1a
Serial No. Prefix: QCK
Item ViewSonic P/N Ref. P/N Description Q'ty
1 N/A 2024272901P FRONT BEZEL GCABA2369T8F...MGY 1
2 N/A 2044269101P FUNCTION KEY JKNBP2392T8F...MGY 1
3 N/A 2053756001P LED INDIC.-PWR HDECP2012TSF VP930 1
4 N/A 2202525100P PCB MULTILAYER VP930-2 K/B FR4*2 108*9 1
5 N/A 2051353800P NAME PLATE VIEWSONIC BIRD LOGO H:8MM 1
6 E-00008011 2212090200P LCD PANEL M190EG01-V0 AUO 1
7 N/A 2071881300P BRACKET,FIX LANGF2232T8 VP930B 2
8 N/A 2071979700P METAL FITTG LANGF2227T8 VP930B 1
9 N/A 2061456300P BUSHING PCUSG1687T8 VP930B 1
10 B-00005311 2200501400P PC BOARD ASS'Y SMD RUNTP5654T8 (POWER/B) SAMPO RA 1
11 B-00008020 2200501500P PC BOARD ASS'Y SMD RUNTP5656T8 (POWER/B) SAMPO RB 1
12 C-00005329 2022267501P CABI BACK GCABB1883T8F...MGY 1
13 N/A 2071881100P BRACKET,FIX LANGF2194T8---A VP930 4
14 N/A N.A BUSHING PCUSG1671T8 VP930B 1
15 C-00005329 2022267401P CABI BACK GC0VD2626T8F...MGY 1
16 N/A N.A BUSHING PCUSG1671T8 VP930B 1
17 N/A 2202525000P PCB MULTILAYER VP930-2 M/B FR4*2 120*110 1
18 N/A 2061456400P BUSHING PCUSG1651T8--- 1
19 B-00005310 2200501200P PC BOARD ASS'Y SMD RUNTP5655T8 (INVERTER) SAMPO RA 1
20 B-00008021 2200501300P PC BOARD ASS'Y SMD RUNTP5663T8 (INVERTER) SAMPO RB 1
21 N/A 2072461300P INSULATOR PISLV0262T8---- 1
22 N/A N/A PROTECTOR PISL-1951T8 VP930B 3
23 N/A 2080006100P SCREW,SPE XBPSB40P10JS0 (M4*10) VP930B 1
24 N/A N/A PROTECTOR PISL-1588T8 VP930B 1
25 N/A N/A HINGE COVER GCOVD2632T8F 1
26 N/A N/A HINGE COVER GCOVD2633T8F 1
27 N/A N/A HINGE BODAY MHNGM0067T8 1
28 N/A N/A NECK FRONT GCOVD2630T8F 1
29 N/A N/A NECK BACK GCOVD2631T8F 1
30 N/A N/A CABLE FIED GCOVD2634T8F 3
31 N/A N/A 19"BASE GSTN-2950T8F 1
32 N/A N/A 19"BASE-METAL LANGF2229T8 1
EXPLODED PARTS LIST (VP930-3)
ViewSonic Corporation Confidential - Do Not Copy VP930-3_VP930b-3
58
