Get Funcon Length ID Command Command
Response
Range
Comments
Get-Function On_
Off *3.3.2
8 G = 3D
001: Backlight OFF
101: Backlight ON
002: Freeze OFF
102: Freeze ON
003: Touch OFF
103: Touch ON
NOTE:
1. Get Date example
Assumed the current date of display#01 as below:
Date: 2017-3/15
Send: 0x 38 30 31 67 32 59 30 30 0D (Get Date:Year)
Reply: 0x 38 30 31 72 32 59 31 37 0D (“Y17”)
Send: 0x 38 30 31 67 32 4D 30 30 0D (Get Date:Month)
Reply: 0x 38 30 31 72 32 4D 30 33 0D (“M03”)
Send: 0x 38 30 31 67 32 44 30 30 0D (Get Date:Day)
Reply: 0x 38 30 31 72 32 44 31 35 0D (“D15”)
2. Get Time example
Assumed the current me of display#01 as below:
Time: 16:27:59
Send: 0x 38 30 31 67 33 48 30 30 0D (Get Time:Hour)
Reply: 0x 38 30 31 72 33 48 31 36 0D (“H16”)
Send: 0x 38 30 31 67 33 4D 30 30 0D (Get Time:Min)
Reply: 0x 38 30 31 72 33 4D 32 37 0D (“M27”)
Send: 0x 38 30 31 67 33 53 30 30 0D (Get Time:Sec)
Reply: 0x 38 30 31 72 33 53 35 39 0D (“S59”)
3. Get Smart hub example
Assumed Amb_Temp is -5 deg C, Amb_Humidity is 30%, Amb_Light is 80, Amb_
PIR detecon is 1
Send: 0x 38 30 31 67 3A 30 30 30 0D (Get all Smart hub info)
Reply: 0x 32 30 31 72 3A 41 2D 30 35 2E 30 42 30 33 30 2E 30 43 30 30 30 38
30 44 30 30 30 30 31 00 00 00 0D (A-05.0B030.0C00080D00001)
Send: 0x 38 30 31 67 3A 30 30 41 0D (Get Amb_Temp only)
Reply: 0x 32 30 31 72 3A 41 2D 30 35 2E 30 00 00 …00 00 0D (A-05.0)
