ViewSonic Corporation Confidential - Do Not Copy VG2230wm-1
8
Max Input AC Current 1.5 Arms @ 90VAC, 0.75 Arms @180VAC
Inrush Current (Cold Start)
50 A (max) @ 115VAC
90 A (max) @ 230VAC
Power Supply Cold Start
Shall start and function properly when under full load, with
all combinations of input voltage, input frequency, and
operating temperature.
Power Supply Transient Immunity
Shall be able to withstand an ANSI/IEEE C62.41-1980
6000V 200 ampere ring wave transient test with no damage.
Power Supply Line Surge Immunity
Shall be able to withstand 1.5 times nominal line voltage for
one cycle with no damage.
Power Supply Missing Cycle Immunity
Shall be able to function properly, without reset or visible
screen artifacts, when ½ cycle of AC power is randomly
missing at nominal input.
Power Supply Acoustics
The power supply shall not produce audible noise that would
be detectable by the user. Audible shall defined to be in
compliance with ISO 7779 (DIN EN27779:1991) Noise
measurements of machines acoustics. Power Switch noise
shall not be considered.
Power Saving Operation(Method) VESA DPMS Signaling
Power Consumption
Mode LED Power Consumption
On Blue 38W (typ)
43W (max)
Active off Amber <1W
Off Off <1W
Recovery Time On Mode = N/A, Active Off < 3 sec
2.5 ELECTRICAL REQUIREMENT
Horizontal / Vertical Frequency
Horizontal Frequency
24 – 82 kHz
Vertical Refresh Rate
50 – 85 Hz
Maximum Pixel Clock 165 MHz
Sync Polarity Independent of sync polarity
