Timing Table
Analog
Item
Timing
Separated
Composite
SOG
Digital - TMDS
Remark
1 640 x 350 @ 70 Hz, 31.5 KHz
2 640 x 350 @ 85 Hz, 37.9 KHz
3 640 x 400 @ 60 Hz, 31.5 KHz
4 640 x 400 @ 70 Hz, 31.5 KHz
5 640 x 400 @ 85 Hz, 37.9 KHz
6 640 x 480 @ 50 Hz, 24.7 KHz
7 640 x 480 @ 60 Hz, 31.5 KHz
8 640 x 480 @ 67 Hz, 35 KHz
9 640 x 480 @ 72 Hz, 37.9 KHz
10 640 x 480 @ 75 Hz, 37.5 KHz
11 640 x 480 @ 85 Hz, 43.3 KHz
12 720 x 400 @ 70 Hz, 31.5 KHz
13 720 x 400 @ 85 Hz, 37.9 KHz
14 720 x 480 @ 60 Hz, 31.5 KHz
15 720 x 576 @ 50 Hz, 31.3 KHz
16 800 x 600 @ 56 Hz, 35.1 KHz
17 800 x 600 @ 60 Hz, 37.9 KHz
18 800 x 600 @ 72 Hz, 48.1 KHz
19 800 x 600 @ 75 Hz, 46.9 KHz
20 800 x 600 @ 85 Hz, 53.7 KHz
21 832 x 624 @ 75 Hz, 49.7 KHz
22 1024 x 768 @ 50 Hz, 39.6 KHz
23 1024 x 768 @ 60 Hz, 48.4 KHz
24 1024 x 768 @ 70 Hz, 56.5 KHz
25 1024 x 768 @ 75 Hz, 60 KHz
26 1024 x 768 @ 75 Hz, 60.2 KHz
27 1024 x 768 @ 85 Hz, 68.7 KHz
28 1152 x 864 @ 75 Hz, 67.5 KHz
29 1152 x 870 @ 75 Hz, 68.7 KHz
30 1280 x 720 @ 50 Hz, 37.5 KHz
31 1280 x 768 @ 50 Hz, 39.6 KHz
32 1280 x 768 @ 60 Hz, 47.4 KHz
33 1280 x 768 @ 60 Hz, 47.8 KHz
34 1280 x 768 @ 75 Hz, 60.3 KHz
35 1280 x 768 @ 85 Hz, 68.6 KHz
