6
2-2. The Exterior of the Monitor
A. Front B. Left and Right
C. Rear
241 3
1. Control panel
(Expanded in 3-1)
2. I/O port (input/output)
This area should include all I/O connection
options, as well as the power input
connector (Expanded in 2-4)
3. Kensington security slot
(Expanded in 2-3 section G)
4. VESA wall mounting
This area on the back of the monitor*. For
the VESA wall mounting installation steps,
please see 2-3 section F for additional
instructions.
