ViewSonic VS17287

11
2-4. Quick Installation
Connect Signal Cables
1. Make sure both the LCD monitor and computer are turned OFF.
2. Remove rear panel covers if necessary.
3. Connect the signal cables from the LCD monitor to the
computer.
USB
USB Audio in Audio out
HDMI
DisplayPort
Power Connector VGA
