5. Specifications
LCD Type TFT (Thin Film Transistor), Active Matrix
1920X1080 LCD, 0.3114 mm x 0.1038 mm
pixel pitch
Display Size Metric: 68.60 cm
Imperial: 27” (27” viewable)
Color Filter RGB vertical stripe
Glass Surface Anti-Glare
Input Signal Video Sync RGB Analog (75 ohms, 0.7 / 1.0 Vp-p)
(Timing Max limited support 1920 x 1080
75Hz)
HDMI (v2.0) (Timing Max limited support
1920 x 1080 @144Hz)
TMDS digital (100ohms)
f
h
:53-160 kHz, f
v
:48-144 Hz
Compatibility PC Up to 1920 x 1080 Non-interlaced
Macintosh Power Macintosh up to 1920 x 1080
(Supported by limited graphic cards)
Resolution
1
Recommended 1920 x 1080@60Hz
Supported 1920 x 1080 @ 144 Hz, 120Hz, 100Hz
1680 x 1050 @ 60 Hz
1440 x 900 @ 60 Hz
1280 x 1024 @ 60, 75 Hz
1024 x 768 @ 60, 70, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 72, 75 Hz
720 x 400 @ 70 Hz
Power
Adaptor
2
Input Voltage 100-240 VAC, 50/60 Hz (auto switch)
