ViewSonic VX2035wm User Manual

ViewSonic VX2035wm 9
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls which display
on the screen. The OSD controls are explained at the top of the next page and are defined in
“Main Menu Controls” on page 11.
Main Menu
with OSD controls
Front Control Panel
shown below in detail
Scrolls through menu
options and adjusts the
displayed control.
Also a shortcut to display
the Contrast adjustment
control screen.
Displays the control screen for
the highlighted control.
Also toggles between two
controls on some screens.
Also a shortcut to Auto Image
Adjust.
Standby Power On/Off
Power light
Blue = ON
Orange = Power Saving
Displays the Main
Menu or exits the
control screen and
saves adjustments.

ViewSonic VX2035wm Specifications

Display

display area	17.1" horizontal x 10.7" vertical; 20.1" diagonal
optimum resolution	1680x1050
contrast ratio	800:1 (typ)
viewing angles	160° horizontal, 160° vertical
response time	5ms white-black-white (typ); 8ms gray-to-gray (avg)
brightness	300 cd/m2 (typ)

Power

voltage	AC 100–240V, 50–60Hz
power consumption	43W (typ)

Audio

speakers	2x1.5-watt

Operating Environment

operating temperature	32–104°F (0–40°C)
operating humidity	20–90% (non-condensing)

Weight and Dimensions

physical dimensions with stand	19.3" x 18" x 9.6" (491mm x 458mm x 244mm)
physical dimensions without stand	19.3" x 14.3" x 2.8" (491mm x 364mm x 70mm)
net weight with stand	15.4 lb. (7.0 kg)
net weight without stand	12.8 lb. (5.8 kg)
gross weight with stand	18.9 lb. (8.6 kg)
