ViewSonic VX2716 User Manual

11
Wall Mounng
NOTE: 
100 mm
100 mm
Refer to the table below for the standard dimensions for wall mount kits.
Maximum
Loading
Hole paern
(W x H)
Interface Pad
(W x H x D)
Pad Hole
Screw Specicaon
& Quanty
14 kg 100 x 100 mm 115 x 115 x 2.6 mm Ø 5 mm
M4 x 10 mm
4 pieces
NOTE: Wall mount kits are sold separately.
1. 
2. 
3. Remove the monitor stand.
4. 
device. Then secure it with four (4) screws (M4 x 10 mm).
5. 
monitor onto the wall.

ViewSonic VX2716 Specifications

General

Color depth	8 bit
Color gamut	72 %
Pixel pitch	0.311 x 0.311 mm
Screen shape	Flat
Display diagonal	27 \
Surface hardness	3H
Anti-glare screen	Yes
Display technology	LED
Native aspect ratio	16:9
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.7 million colors
Digital vertical frequency	48 - 100 Hz
Digital horizontal frequency	24 - 115 kHz
Display brightness (typical)	300 cd/m²
HDMI version	1.4
Headphone out	-
DisplayPort version	1.2
RMS rated power	4 W
Number of speakers	2
AC input voltage	100 - 240 V
Power consumption (max)	28 W
Power consumption (standby)	0.5 W
Power consumption (typical)	19 W
Tilt angle range	-5 - 20 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 90 %
Package depth	445 mm
Package width	680 mm
Package height	143 mm
Package weight	6400 g
Product color	Black
Market positioning	Gaming

Weight and Dimensions

Depth (with stand)	237 mm
Width (with stand)	612 mm
Height (with stand)	432 mm
Weight (with stand)	4800 g
Depth (without stand)	49 mm
Height (without stand)	364 mm
Weight (without stand)	4100 g
