ViewSonic VX715 7
Using the LCD Display
Setting the Timing Mode
Setting the timing mode is important for maximizing the quality of the screen image and
minimizing eye strain. The timing mode consists of the resolution (example 1280 x 1024) and
refresh rate (or vertical frequency; example 60 Hz). After setting the timing mode, use the
OSD (On Screen Display) controls to adjust the screen image.
For the best picture quality set your LCD display timing mode to:
VESA 1280 x 1024 @ 60Hz.
To set the Timing Mode:
1. Set the resolution: Right-click on the Windows desktop > Properties > Settings > set the
resolution.
2. Set the refresh rate: See your graphic card's user guide for instructions.
WAR NI NG: Do not set the graphics card in your computer to exceed a resolution of 1280 x
1024@75Hz or the maximum refresh rate of 85Hz at lower resolutions; doing so may result in
permanent damage to your LCD display.
OSD and Power Lock Settings
• OSD Lock: Press and hold [1] and the up arrowSfor 10 seconds. If any buttons are pressed
the message OSD Locked will display for few seconds.
• OSD Unlock: Press and hold [1] and the up arrowSagain for 10 seconds.
• Power Button Lock: Press and hold [1] and the down arrowTfor 10 seconds. If the power
button is pressed the message Power Button Locked will display for few seconds. With or
without this setting, after a power failure, your LCD display’s power will automatically turn
ON when power is restored.
• Power Button Unlock: Press and hold [1] and the down arrowTagain for 10 seconds.
