ViewSonic VX924 Service Manual

z TFT LCD PANEL
1
st
Source Panel
Model number AUO M190EN04 V5
Type TN type with LVDS interface
Active Size 376.32 (H) x 301.06 (V)
Pixel Arrangement RGB Vertical Stripe
Pixel Pitch 0.294 mm
GLASS TREATMENT Anti Glare (Hard coating 3H)
# OF BACKLIGHTS 4 CCFL edge-light (2 top / 2 bottom)
BACKLIGHT LIFE 50,000 Hours (Min)
Luminance (5-point) –
Condition:
CT = 6500K, Contrast = Max, Brightness = Max
275 cd/m2 (Typ after 30 minute warm up)
215 cd/m2 (Min after 30 minute warm up)
Brightness Uniformity
≧70% Entire Area (min)
Contrast Ratio 550:1 (typ), 350:1 (min)
Color Depth 16.2 million colors (6 bits + 2 bits FRC)
Viewing Angle (Horizontal) @ CR>10
Typical: 140º
Minimum: 130º
Viewing Angle (Vertical) @ CR>10
Typical: 135º
Minimum: 125º
Response Time
10%-90% @ Ta=25°C
Total = 4.8ms (black – white)
(Tr=3.4ms, Tf=1.4ms)
Total = 4.0ms (gray – gray)
Panel Defects Please see Panel Quality Specifications.
9
ViewSonic Corporation Confidential
-
Do Not Copy VX924
