ViewSonic VX924 Service Manual

3.2 Power
3.2.1 Power supply
Input voltage 100~240Vac
Power frequency 50~60Hz
<1.5A RMS @90V AC
<0.8A RMS @180V AC
Input current
Inrush current
50A(Max) at 120Vac(cold start)
Power consumption 35W(typical);40Watts(Max)
3.2.2 Power Management
State Power Indicator
On 35Watts Green
Standby < 1Watts Amber
Off <1Watts Off
3.3 Acceptable timing
This LCD display can automatically detect and display input signals whose timing falls within the
following limits.
Horizontal: Sync frequency: 30~82 kHz
Vertical: Sync frequency: 56~75Hz
3.4 Signal level and input impedance
3.4.1 Video signal level: 0.7Vp-p
3.4.2 Sync signal level - H/V separate: TTL level
3.4.3 Input impedance
Analog video input: 75 ohm
Digital video input: 100 ohm
Sync input: > 1 k ohm
Audio input: 10K ohm
4. Signal Cable: Signal cable with Mini D-Sub 15P connectors at both ends. Length: 1.8 meter.
19
ViewSonic Corporation Confidential
-
Do Not Copy VX924
