ViewSonic VX924 Service Manual

5. EDID data
AUO
Analog EDID
128 BYTES OF EDID CODE:
0 1 2 3 4 5 6 7 8 9
________________________________________
0 | 00 FF FF FF FF FF FF 00 5A 63
10 | 1C 0F 01 01 01 01 01 0F 01 03
20 | 0E 26 1E 78 2E 68 75 A2 5A 49
30 | 9F 23 13 50 54 BF EF 80 81 80
40 | 71 4F 61 59 45 59 31 59 01 01
50 | 01 01 01 01 30 2A 00 98 51 00
60 | 2A 40 30 70 13 00 78 2D 11 00
70 | 00 1E 00 00 00 FF 00 50 53 33
80 | 30 35 30 31 30 30 30 30 31 0A
90 | 00 00 00 FD 00 32 55 1E 52 0E
100 | 00 0A 20 20 20 20 20 20 00 00
110 | 00 FC 00 56 58 39 32 34 0A 20
120 | 20 20 20 20 20 20 00 D3
__________ _______________________________________
(08-09) ID Manufacturer Name = VSC
(11-10) P roduct ID Code = 0F1C
(12-15) Last 5 Digits of Serial Number = Not Used
(16) Week of Manufacture = 01
(17) Year of Manufacture = 2005
(10-17) Complete Serial Number = See Descriptor Block
(18) EDID Version Number = 1
(19) EDID Revision Number = 3
(20) VIDEO INPUT DEFINITION:
Analog Signal
0.700, 0.300 (1.000 Vp-p)
Separate Syncs, Composite Sync, Sync on Green
(21) Maximum Horizontal Image Size = 380 mm
(22) Maximum Vertical Image Size = 300 mm
(23) Display Gamma = 2.20
(24) Power Management and Supported Feature(s):
Active Off/Very Low Power, Standard Default Color Space,
Preferred Timing Mode
Display Type = R/G/B Color
(25-34) CHROMA INFO:
Red X - 0.634 Green X - 0.287 Blue X - 0.138 White X - 0.313
Red Y - 0.354 Green Y - 0.621 Blue Y - 0.077 White Y - 0.329
800 X 600 @ 56Hz (VESA)
800 X 600 @ 60Hz (VESA)
(35) ESTABLISHED TIMING I:
720 X 400 @ 70Hz (IBM,VGA)
640 X 480 @ 60Hz (IBM,VGA)
640 X 480 @ 67Hz (Apple,Mac II)
640 X 480 @ 72Hz (VESA)
640 X 480 @ 75Hz (VESA)
20
ViewSonic Corporation Confidential
-
Do Not Copy VX924
