z POWER SUPPLY
Internal Power Supply Part Number: FSP035-1PI01
Input Voltage Range 90 TO 264 VAC
Input Frequency Range 47.5 TO 63 HERTZ
Short Circuit Protection Output can be shorted without damage
Over Current Protection 3.5 A typical at 12.0 VDC ( Protect when short circuit )
Leakage Current 0.75mA (Max) at 264VAC / 50Hz
EFFICIENCY 77 % typical at 115VAC Full Load
Fuse Internal and not user replaceable
Power Dissipation 35 Watts (typ)
Max Input AC Current 1.2 Arms @ 90VAC, 0.7 Arms @265VAC
INRUSH CURRENT (COLD START) 60 A @ 115VAC
Power Supply Cold Start
Shall start and function properly when under full load,
with all combinations of input voltage, input frequency,
and operating temperature
Power Supply Transient Immunity
Shall be able to withstand an ANSI/IEEE C62.41-1980
2000V 200 ampere ring wave transient test with no
damage
Power Supply Line Surge Immunity
Shall be able to withstand 1.5 times nominal line voltage
for one cycle with no damage
Power Supply Missing Cycle Immunity
Shall be able to function properly, without reset or visible
screen artifacts, when ½ cycle of AC power is randomly
missing at nominal input
Power Supply Acoustics
The power supply shall not produce audible noise that
would be detectable by the user. Audible shall defined
to be in compliance with ISO 7779 (DIN EN27779:1991)
Noise measurements of machines acoustics. Power
Switch noise shall not be considered
US Type Power Cable
Separate 3-prong NEMA 5-15P type plug. Length =
1.8m. Connects to display.
Color = Black
European Type Power Cable
Schuko CEE7-7 type plug.
Length = 1.8m, Connects to display.
Color = Black
6
ViewSonic Corporation Confidential
-
Do Not Copy VX924
