Page #10 background imageLoading...
Page #10 background image
CCC Type Power Cable
Separate 3-prong type plug.
Length = 1.8m. Connects to display.
Color = Black
PSE Type Power Cable
Separate 2-prong NEMA 1-15P type plug. Length =
1.8m. Connects to display.
Color = Black
Power Saving Operation(Method)
VESA DPMS Signaling
ON Mode < 40 W (Max) / 35 W (Typ)
Power Consumption
On Mode < 40 W (Max) / 35 W (Typ)
Saving Mode < 2 W, Off Mode < 1 W
Recovery Time On Mode = N/A, Active Off < 3 sec
z ELECTRICAL REQUIREMENT
Horizontal / Vertical Frequency
Horizontal Frequency 30 – 82 KHZ
Vertical Refresh Rate 50 – 75 HZ
Maximum Pixel Clock 135 MHz
Sync Polarity Independent of sync polarity.
z Timing Table
Item Timing Analog Digital
1 640 x 350 @ 70Hz, 31.5kHz Yes Yes
2 640 x 400 @ 60Hz, 31.5kHz Yes Yes
3 640 x 400 @ 70Hz, 31.5kHz Yes Yes
4 640 x 480 @ 50Hz, 24.7kHz Yes No
5 640 x 480 @ 60Hz, 31.5kHz Yes Yes
6 640 x 480 @ 67Hz, 35.0kHz Yes Yes
7 640 x 480 @ 72Hz, 37.9kHz Yes Yes
8 640 x 480 @ 75Hz, 37.5kHz Yes Yes
9 640 x 480 @ 85Hz, 43.27kHz No No
10 720 x 400 @ 70Hz, 31.5kHz Yes Yes
11 800 x 600 @ 56Hz, 35.1kHz Yes Yes
12 800 x 600 @ 60Hz, 37.9kHz Yes Yes
13 800 x 600 @ 75Hz, 46.9kHz Yes Yes
14 800 x 600 @ 72Hz, 48.1kHz Yes Yes
15 800 x 600 @ 85Hz, 53.7kHz No No
16 832 x 624 @ 75Hz, 49.7kHz Yes Yes
7
ViewSonic Corporation Confidential
-
Do Not Copy VX924
