ViewZ VZ-097RCR-D User Manual

▶ PIN ASSIGNMENTS
Pin 1
RED VIDEO
9
2
GREEN VIDEO
10
SIGNAL CABLE DETECT
3
BLUE VIDEO
11
GROUND
4
GROUND
12
SDA(for DDC)
5
GROUND
13
H-SYNC.(or H+V SYNC.)
6
RED GROUND
14
V-SYNC.
7
GREEN GROUND
15
CL(for DDC)
8
BLUE GROUND
D-SUB
▶ ACCESSORY
1. Power adaptor x(2)
2. User’s manual
3. Cable (PC or HDMI) x(2)
4. Trigger cable (Option) x(2)
5. Stereo cable (Option) x(2)
16 …………………………………………….……………………………INSTRUCTION MANUAL
