Viking Range VCBB363 - Insert Dimensions; Top View; Front View

29
HINGE COVER DIMENSIONS
1/2” (1.3 cm)
3-1/8”
(7.9 cm)
1/4” (0.6 cm)
26
o
23/32”
(1.8 cm)
Hinge cover protrudes 9/32” (0.7 cm) beyond wood grille
35-1/2 (90.2 cm)
INSERT DIMENSIONS
TOP VIEW
FRONT VIEW
Right View
