Viking Range VCBB363 - Bottom View

28
REAR VIEW DIMENSIONS
TOP AND BOTTOM VIEW DIMENSIONS
ENDS DIMENSIONS
32-3/16” (81.8 cm)
34” (86.4 cm)
30-27/32” (78.3 cm)
5-17/32”
(14.0 cm)
4-11/64”
(10.6 cm)
3/8” (0.95 cm)
1/2” (1.3 cm)
3/4” (1.9 cm)
3 3/4”
(9.5 cm)
TOP VIEW
RIGHT VIEW
LEFT FRONT VIEW
1/2”
(1.3 cm)
3/4”(1.9 cm)
3 3/4”(9.5 cm)
1/8”(0.3 cm)
3”
(7.6 cm)
Bottom View
R1/4”
Route a 1/2” (1.3cm) wide by 1/2” (1.3 cm) deep slot
centered in bottom of end panel over hinge point.
Bottom of end panel
RIGHT FRONT VIEW
(dimensions mirrored from left front view)
BOTTOM VIEW
