12
Anti-Tip Dimensions
WARNING
TIP OVER HAZARD
Appliance is top heavy and tips easily when not
completely installed. To avoid a hazard due to instability
of the appliance, it must be installed according to the
instructions including the anti-tip bracket
C
C
Cabinet
Rear
Floor
A
Cabinet
Opening
Dimension A = Cabinet opening minus the refrigerator height + 1-1/4" (3.2 cm)
Anti-tip Bracket
The anti-tip bracket has holes set up on a grid in order to better locate a
wall stud. At least 4 places must be used.
NOTE: Number and type of fasteners must be suitable in order to
prevent tipping. For example: use wood screws into wall studs or
masonry anchors if attaching to stone, brick or concrete.
If a wall stud can not be found, use
the lower section of the bracket
and mount to the base board
