Door Stop Adjustment
Your refrigerator is factory set at a 90
o
degree opening. The 90 degree door stop opening is shown in the illustration below with the long end of
the door stop facing away from the door. To change to 105
o
door stop, locate the door stop on top of the door hinge. Remove the two screws
and door stop. Rotate the door stop 180
o
degrees so that the shorter end faces away from the door. Replace door stop and screws.
For additional information on the door stop adjustment, visit the product information tab for 7 Series Bottom Mount Refrigerators online at
vikingrange.com in the US or brigade.ca in Canada.
Door Stop
Remove screws and
door stop
Rotate 180
o
degrees Replace door stop and
screws
Long end of door stop
