Viking DDSF136DSS - Opening Dimensions; Door Swing Dimensions

5
Product Dimensions
Opening Dimensions
Height dimensions are shown with the leveling legs extended to the minimum height of •
1
⁄4” (6.35 mm)
below the refrigerator.
NOTE: When leveling legs are fully extended to 1” (25 mm) below the refrigerator, add
3
⁄4” (19 mm) to
the height dimensions.
Minimum fixed wall position is 13
•
1
⁄4” (34 cm) from the freezer door and 16
1
⁄2” (42 cm) from the refrig-
erator door.
Door Swing Dimensions
Location must permit doors to open to a minimum of 150°. Allow 13
1
⁄4” (34 cm) minimum space between
the side wall and the freezer side of the refrigerator. Allow 16
1
⁄2” (42 cm) minimum
space between the side wall and the refrigerator side.
13
5
/
8
"
(34.5 cm)
41
3
/
4
"
(106 cm)
2
5
/
8
"
(6.6 cm)
1
/
2
"
(12.7 mm)
17"
(43.0 cm)
0"
(0.1 mm)
45
1
/
2
"
(115.6 cm)
90°
150°
Installation Requirements
69“
(175.3 cm)
