Viking FDRB5301R - Clearance Dimensions - Professional

REFRIGERATION
Quiet Cool™ Built-In 30”W. All Refrigerator
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
1-13/16”
(4.6 cm)
space if 24” standard
cabinet depth is used
Door
24”
(61.0 cm)
standard cabinet depth
Wall
3/4”
(1.9 cm)
full end panel
1-3/4”
(4.4 cm) offset
Partial overlay
cabinet door
Door
Wall
1-13/16”
(
4.6 cm)
s
pace if 24” standard
c
abinet depth is used
3/4”
(1.9 cm)
full end panel
24”
(61.0 cm)
standard
cabinet
depth
1-3/4”
(4.4 cm) offset
5/16”
(0.8 cm)
1-13/16”
(
4.6 cm)
space if 24” standard
cabinet depth is used
D
oor
24”
(
61.0 cm)
s
tandard cabinet depth
W
all
3/4”
(1.9 cm)
full end panel
1-3/4”
(4.4 cm) offset
Countertop
overhang
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL
TOP VIEW
TOP VIEW
TOP VIEW
R E L E A S E D 2 / 2 0 / 1 2
© 2 0 1 2 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
