Viking FDRB5301R - Clearance Dimensions - Professional With Flush Mount Trim

REFRIGERATION
Quiet Cool™ Built-In 30”W. All Refrigerator
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M • 1 - 8 8 8 - V I K I N G 1
Door
Wall
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
3/4”
(1.9 cm)
full end panel
25”
(63.5 cm)
Flush
D
oor
2
4”
(61.0 cm)
standard
cabinet depth
25”
(63.5 cm)
countertop
depth
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depth is used
Flush
Dimensions & Specifications
CLEARANCE DIMENSIONS—PROFESSIONAL WITH FLUSH MOUNT TRIM
Door
2
4
”
(
6
1
.
0
c
m
)
s
t
a
n
d
a
r
d
c
a
b
i
n
e
t
d
e
p
t
h
24-3/4”
(62.9 cm)
Wall
3/4”
(1.9 cm)
full end panel
1”
(2.5 cm)
if 25” (63.5 cm)
cabinet depthis used
Flush
Cabinet
door
TOP VIEW
TOP VIEW
TOP VIEW
Overlapping cabinet doors
