16
E
Product Controls
Features
1 One touch door open button
Push to open door.
2 Oven door with see-
through window
CAUTION
Be careful with the edge of the
oven door as it is glass and could
chip or break.
3 Safety door latches
The oven will not
operate unless the door
is securely closed.
4 Door hinges
5 Door seals and
sealing surfaces
6 Turntable motor shaft
7 Removable turntable support
Carefully place the
turntable support in the
center of the oven floor.
8 Removable turntable
Place the turntable on
the turntable support
securely. The turntable
will rotate clockwise or
counterclockwise. Only
remove for cleaning.
9 Ventilation openings (Rear)
10 Oven light
It will light when oven is
operating or door is open.
11 Waveguide cover:
DO NOT REMOVE
12 Auto-Touch control panel
13 Cook and Time display:
99 minutes, 99 seconds
14 Rating Label
8
7
1
23 3
5 9 10
12
11
13
4 6
14
Front View
