Wiring Diagrams and Schematics
© Viking Range Corporation SMC-0002 17
EARTH
N
A
S6 S5 S4 S3 S2 S1
S1S2S3S4S5S6
GRD
GRD
IGN1
IGN2
IGN3
IGN4
IGN5
IGN6
SWITCH 1SWITCH 2
SWITCH 3
SWITCH4
SWITCH 5
SWITCH 6
WARNING-
ELECTRICAL GROUNDING INSTRUCTIONS
THIS APPLIANCE IS EQUIPPED WITH A THREE PRONG
GROUNDING PLUG FOR YOUR PROTECTION AGAINST SHOCK
HAZARD AND SHOULD BE PLUGGED DIRECTLY INTO A PROPERLY
GROUNDED THREE-PRONGED RECECPTACLE. DO NOT CUT OR
REMOVE THE GROUNDING PRONG FROM THE PLUG.
L1
N
SPARK MODULE
REFER ONLY TO FEATURES EQUIPPED WITH THIS UNIT.
SERVICING CONTROLS.
WIRING ERRORS CAN CAUSE
IMPROPER AND DANGEROUS OPERATION.
VERIFY PROPER OPERATION AFTER SERVICING.
LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN
CAUTION-
EARTH
N
A
S4 S3 S2 S1
S1
GRD
S4 S3 S2
GRD
IGN1
IGN2
IGN3
IGN4
SWITCH 1SWITCH 2
SWITCH 3
SWITCH4
WARNING-
ELECTRICAL GROUNDING INSTRUCTIONS
THIS APPLIANCE IS EQUIPPED WITH A THREE PRONG
GROUNDING PLUG FOR YOUR PROTECTION AGAINST SHOCK
HAZARD AND SHOULD BE PLUGGED DIRECTLY INTO A PROPERLY
GROUNDED THREE-PRONGED RECECPTACLE. DO NOT CUT OR
REMOVE THE GROUNDING PRONG FROM THE PLUG.
L1
N
SPARK MODULE
REFER ONLY TO FEATURES EQUIPPED WITH THIS UNIT.
SERVICING CONTROLS.
WIRING ERRORS CAN CAUSE
IMPROPER AND DANGEROUS OPERATION.
VERIFY PROPER OPERATION AFTER SERVICING.
LABEL ALL WIRES PRIOR TO DISCONNECTION WHEN
CAUTION-
VGSU163
VGSU103
