9
10. Fold the inner section of the left hand side
towards the middle, so that the release unit
is visible.
11. Zip the rest of the cover. Remember to pull the
release handle through the hole in the cover.
Close hook/loop closure and insert zipper ends
into the cover.
IMPORTANT: The release handle must be located
as in packing photo. Release line and handle
must hang out from the bottom edge of the
velcro.
Packing instruction for lifejacket with sprayhood
(only 275N version)
If the lifejacket has a sprayhood the above mentioned
packing instruction must be followed until the above
mentioned item 5 and then the following packing
instruction apply:
6. Fold the sprayhood three times. Fold the
neck like a fan with the welding visible. Place
the sprayhood into the neckfolds. Make sure the
welding on the neck is still visible.
7. Left corner is folded so that the welding is on
top. The cover is zipped up to the middle of the
neck.
8. Right corner of the neck is folded so that the
welding is on top. The cover is zipped a bit more
to cover the corner. Mount lifting strap.
9. Fold up the bottom section on the right side of
the buoyancy chamber. The release unit must be
visible.
10. Fold the inner section on the right hand side
towards the middle so that the release unit is
visible.
11. Fold the inner section of the left hand side
towards the middle, so that the release unit is
visible.
12. Zip the rest of the cover. Remember to pull the
release handle through the hole in the cover.
Close hook/loop closure and insert zipper ends
into the cover.
IMPORTANT: The release handle must be located
as in packing photo. Release line and handle
must hang out from the bottom edge of the
velcro.
4.4 REPLACEMENT OF CO
2
-CYLINDER AND BOBBIN
After use in fresh water dry the lifejacket. If the lifejacket
has been used in salt water, it must be rinsed with fresh
water and then dried. Empty the lifejacket of air using
the oral inflation valve.
a. Unscrew the automatic holder (8) and throw
away the bobbin (7). Rinse the holder carefully
in fresh water and dry it carefully.
b. Unscrew and discard used CO
2
cylinder (1).
c. Place a new bobbin (7) in the inflator. Screw the
automatic holder onto the inflator.
d. The service indicator must be green.
e. If the release arm (3) has been pulled out, press
it back into position and place the indicator clip
(4) over the release arm.
f. Gasket (2) under the CO
2
cylinder must be
removed and discarded. Insert a new gasket
in the inflator (5). Place it right at the bottom of
the inflator.
g. Install the CO
2
cylinder (1) into inflator and hand
tighten.
5. SPARE PARTS
Please contact an approved VIKING servicing station.
Find your nearest servicing station on
www.viking-life.com.
6. STORAGE
We recommend that the lifejacket is stored in a dry
place, possibly suspended on a hanger in a wardrobe.
Unintended inflation may occur. This may be due to a
combination of moisture and vibration. If the annual
service is observed, the risk of this will be reduced.
7. APPLICATIONS AND LIMITATIONS
The lifejacket has been tested in water temperatures
ranging from -1°C to 30°C. At water temperatures below
zero, automatic inflation may be delayed. If so, release
it manually.
Do not ever wear any clothing over the lifejacket. If worn
together with an immersion suit or any special clothing
such as sailors’ wear with buoyancy, the functioning of
the lifejacket may be affected.
VIKING YouSafe
TM
One EN
